D Special conditions for safe use
The equipment is an intrinsically safe equipment. It can be used
in a potentially explosive atmosphere.
The equipment must be powered only by the battery Icom type
BP-227AX.
When the transceiver is used in a hazardous areas, either the
jack cover or HM-138 must be attached to the connector. Failure
to do this will make the radio ATEX non-compliant and may result
in an accident during use in hazardous areas.
The battery shall be charged only in non hazardous areas.
Ambient operating temperature: –20°C to +55°C
D Meaning of ATEX marking codes
CE conformity
marking
Equipment category:
1 (for Zone 0 or 20), 2 (for Zone 1 or 21), 3 (for Zone 2 or 22)
Type of Explosive atmosphere:
G (for gas, vapors and mist), D (for dusts)
Equipment group: I (for mines), II (for other than mines)
Equipment conforms to types of protection stan-
dardized by CENELEC (European standards)
Intrinsic safety
according EN60079-0
Marking temperatures (see Fig. 1)
and EN60079-11
Explosion protection
marking
Identification number of notified body
(where appropriate) (LCIE: 0081)
Gas Group (see Fig. 1)
Gas/Equipment
Protection Level (EPL)

ATEX CAUTIONS

Group Gas
17
(Fig. 1)
33
