Digicast Media Router S2 Receiver CMR-5975 (MR-S2)
Interface Pinouts
3.3

RJ-45 Ethernet

3.4

RJ-12 Redundancy

3.5

RJ-12 Terminal

3.6

F-Type L-Band

Pin
1
2
3
4
5
6
7
8
Pin
1
2
3
4
5
6
Pin
1
2
3
4
5
6
Pin
Input 950-2150 MHz
Center
Output +13VDC or + 18VDC 0.6A
Outer Ring
3-2
Definition
TXD+
TXD-
RXD+
N/C
N/C
RXD-
N/C
N/C
Definition
GND
TXD
RXD
GND
N/C
N/C
Definition
GND
TXD
RXD
GND
N/C
N/C
Definition
GND
Revision 1
MN-0000032
