Specifications; Table 1-1. Digicast Media Router S2 Receiver - Specifications - Comtech EF Data MR-S2 Installation And Operation Manual

Digicast Media Router S2 Receiver CMR-5975 (MR-S2)
Introduction
1.5

Specifications

Table 1-1. Digicast Media Router S2 Receiver – Specifications
Parameter
DVB-S
L-Band Tuner
DVB-S2
Dimensions
Weight
Power
L-Band Input
Ethernet
(10/100BaseT)
Terminal
Redundancy
Physical
LEDs
Power Input /
Consumption
L-Band Input
Electrical
Ethernet
(10/100BaseT)
Console
Redundancy
Temperature
Operating
Storage
(Non-operating)
Humidity
Operating
Environmental
Storage
(Non-operating)
Altitude
Operating
Storage
(Non-operating)
( 2 to 45 Msps)
QPSK ( 2 to 32 Msps)
8PSK ( 2 to 32 Msps)
8.75" L x 7.125" W x 1.625" H (22.225 L x 18.0975 W x 4.1.275 H cm)
1.6 lbs. (0.6 kg)
2.5 mm with screw type connector
F-Type (75Ω)
RJ-45
RJ-12
RJ-12
Blue PWR Power indicator
Green RED Redundancy indicator
Red ALARM Flashing when the unit is in an alarm state
Steady light indicates that the receiver has obtained a
Green LOCK
locked signal
Green E-SPD Ethernet speed
Amber E-COL Ethernet collision indicator
Green E-RX Ethernet receive indicator
Green E-TX Ethernet transmit indicator
Green E-LINK Ethernet link indicator
100 to 240 VAC 47/63 Hz converted to +5VDC @ 5.0A/ <25W
DVB-S ETSI EN 300 421
DVB-S2 ETSI EN 302 307
IEEE 802.3u
RS-232
RS-232
32° to 104° Fahrenheit (0° to 40° Celsius)
-22° to 150° Fahrenheit (-30° to 65° Celsius)
10% to 75% Non-condensing
Relative humidity to 95% with temperature ≤ 95° Fahrenheit (35°
Celsius)
Up to 10,000 feet (3048 m) above sea level
Survival up to 50,000 feet (15240 m) above sea level for up to 15 hours
Specification
FEC Rates: 1/2, 2/3, 3/4, 5/6 and 7/8
FEC Rates: 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9 and 9/10
FEC Rates: 3/5, 2/3, 3/4, 5/6, 8/9 and 9/10
1–4
Revision 1
