B.1

Introduction

The MR-S2 provides state-of-the-art L-Band DVB-S and DVB-S2 IP and transport stream
delivery based on the ISO/IEC 13818-1, ISO/IEC 13818-6 and DVB Specification for Data
Broadcasting (EN 301 192).
The MR-S2 provides the following configuration features:
• Support for DVB-S reception at rates from 2 to 45 Msps
•
Support for DVB-S2 reception at rates:
QPSK 2 to 32 Msps
8PSK 2 to 32 Msps
• IP Decapsulation per Multi-Protocol Encapsulation (EN 301 192)
• Unicast Routing
• Multicast Routing
•
Section Packing and Non-Section Packing
•
IGMP version 2
B.2

IP Configuration

Both Unicast and Multicast IP datagrams are encapsulated per the Multiprotocol Encapsulation
MPE specification. Routing of datagrams is accomplished by configuration of PIDs in the MR-
S2, as described in the following sections.
