1.1

Introduction

The TPC-1071H/1271H/1571H/1771H Touch Panel Computers are state-of-the-art
Human Machine Interfaces featuring 10"/ 12"/ 15"/ 17" displays with Intel Atom pro-
cessors 400 and 500 Series with Intel ICH8M I/O Controller and the following key
features:
 Fanless
By using a low-power processor, the system does not have to rely on fans,
which often are unreliable and causes dust to circulate inside the equipment.
 Compact Expansion
With its PCI-E/ mini PCI-E slot, it provides the easiest way to expand TPC's
functionality.
 Multiple OS
In addition to the OS support of Windows XP, Advantech offers platform support
for WES7 and Windows XP embedded. The optional Windows CE operating
system, specifically for Industrial Touch Panel Computers is also available.
 Automation IO Control Module
8 x DI/DO design with isolation for automation monitoring/control application.
 Various Mounting Options
TPC-1071H/1271H/1571H/1771H allows a variety of mounting systems e.g.
panel mount. It has been verified and is recommended to work with vertical
mounting systems.
 RTC Battery Backup SRAM (1MB)
RTC backup ensures real time data management in case of accidental power
failure.
1.2

Packing List

1.2.1

TPC-1071H and 1271H

 8 x Panel Mount Clamps
 8 x Panel Mount Screws
 1 x 3 Pin Power Connector
 1 x Power Indication Sticker
 1 x Wire for Chassis Ground
 1 x TPC Driver DVD
 1 x Registration and Warranty Card
 1 x Simplified Chinese Manual
 2 x 10-pin plug-in block for DI/O port
1.2.2

TPC-1571H and 1771H

 10 x Panel Mount Clamps
 10 x Panel Mount Screws
 1 x 3 Pin Power Connector
 1 x Power Indication Sticker
 1 x Wire for Chassis Ground
 1 x TPC Driver DVD
1 x Registration and Warranty Card

1 x Simplified Chinese Manual

 2 x 10-pin plug-in block for DI/O port
