Packing List

Before setting up the system, check that the items listed below are included and in
good condition. If any item does not accord with the table, please contact the dealer
immediately.
PPC-S155T series panel PC
Users manual
Accessories for PPC-S155T
– Y-shaped adapter for PS/2 mouse and keyboard
– Warranty card
– A power cord is not included with this product, but is available for purchase
as a separate option.
– AC/DC power adapter
– "Drivers and Utilities" CD-ROM disc
– VESA-standard bracket for mounting
– Mounting kits and packet of screws
– Heat sink
– Heat sink support plate kits
– Thermal pad
– Thermal grease
If any of these items are missing or damaged, contact the distributor or sales repre-
sentative immediately.
Note! 1.
2.
3.
4.
If the unit is without a CPU, this is included in the accessory box. If
the unit comes with a CPU, the heat sink is installed in the unit.
If the support plate kits are on the motherboard, then the heat sink
can be installed on the plate.
The thermal pad needs to put around the CPU die as a buffer
between heat sink and CPU.
Put the thermal grease on the CPU die for transferring the heat to
heat sink.
v PPC-S155T User Manual
