- Page 1 WALL CHASER MODEL NO: CON1450WC PART NO: 6462165 OPERATION & MAINTENANCE INSTRUCTIONS LS0109...
- Page 2 INTRODUCTION Thank you for purchasing this CLARKE Wall Chaser. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service.
-
Page 3: General Safety Rules
GENERAL SAFETY RULES WARNING: READ ALL INSTRUCTIONS. FAILURE TO FOLLOW ALL INSTRUCTIONS LISTED BELOW MAY RESULT IN ELECTRIC SHOCK, FIRE AND/ OR SERIOUS INJURY. SAVE THESE INSTRUCTIONS. WORK AREA Keep work area clean and well lit. Cluttered and dark areas invite accidents. Do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases or dust. -
Page 4: Additional Safety Rules For Wall Chasers
POWER TOOL USE AND CARE Do not force the power tool. Use the correct power tool for your application. The correct power tool will do the job better and safer at the rate for which it was designed. Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be controlled with the switch is dangerous and must be repaired. -
Page 5: Kickback And Related Warnings
KICKBACK AND RELATED WARNINGS Kickback is a sudden reaction to a pinched or snagged cutting disc. Pinching or snagging causes rapid stalling of the rotating wheel which in turn causes the uncontrolled power tool to be forced in the opposite direction of the wheels rotation. Maintain a firm grip on the power tool and position your body and arm to allow you to resist kickback forces. -
Page 6: Electrical Connections
ELECTRICAL CONNECTIONS WARNING! Read these electrical safety instructions thoroughly before connecting the product to the mains supply. Before switching the product on, make sure that the voltage of your electricity supply is the same as that indicated on the rating plate. This product is designed to operate on 230VAC 50Hz. -
Page 7: Before Use
BEFORE USE WHAT’S SUPPLIED Unpack your wall chaser and make sure that the following items are present. Should there be any damage caused during transit contact your Clarke dealer immediately. • 1 x Wall Chaser • 1 x Pin Spanner •... - Page 8 REPLACING THE CUTTING DISCS WARNING: Disconnect the plug from the power source before making any adjustments or changing accessories. NOTE: Always replace both discs at the same time. Remove the depth adjustment knob by hand and 3 bolts indicated using the 5mm hex key supplied.
-
Page 9: Fitting The Dust Extraction Assembly
FITTING THE DUST EXTRACTION ASSEMBLY Attach the dust extraction assembly to the wall chaser. • Insert the assembly (1) into the extraction port (2) and rotate slightly clockwise to lock into place. • Remove the collar (4) and slide it over the vacuum cleaner hose. -
Page 10: Operation
OPERATION ADJUSTING THE CUTTING DEPTH 1. Loosen the depth adjustment knob. 2. Raise/lower the baseplate. 3. Use a ruler as shown to measure the depth of the blade (d). 4. Tighten the depth adjustment knob. NOTE: The depth of cut should be 3mm deeper than the required slot depth, this is to compensate for any inaccuracies when you break away the resulting fin after cutting. -
Page 11: Maintenance
MAINTENANCE WARNING: MAKE SURE THAT THE WALL CHASER IS SWITCHED OFF AND DISCONNECTED FROM THE MAINS SUPPLY BEFORE STARTING ANY CLEANING OR MAINTENANCE PROCEDURES. With the exception of changing the blade there are no user serviceable parts in this unit. After use, •... -
Page 12: Specifications
5 Kg PARTS AND SERVICING For Parts & Servicing, please contact your nearest dealer, or CLARKE International, on one of the following numbers PARTS & SERVICE TEL: 020 8988 7400 PARTS & SERVICE FAX: 020 8558 3622 or e-mail as follows: PARTS: Parts@clarkeinternational.com... -
Page 13: Exploded Diagram - Parts List
EXPLODED DIAGRAM - PARTS LIST... - Page 14 EXPLODED DIAGRAM - PARTS LIST DESCRIPTION PART NO DESCRIPTION PART NO Dust extraction CON1450WC01 Roll sheath CON1450WC43 Rubber ring CON1450WC02 Washer CON1450WC44 Pree ring CON1450WC03 Shaft CON1450WC45 Bend tube CON1450WC04 Circlip CON1450WC46 Sealed ring CON1450WC05 Washer CON1450WC47 Connect tube CON1450WC06 Pinion gear CON1450WC48 Aluminium...
-
Page 15: Declaration Of Conformity
DECLARATION OF CONFORMITY...
