DNG-200 LOW FOG GENERATOR
USER MANUAL
DNG-200 低煙機使用說明書
Read and save these insturctions
2008 Antari Lighting & Effects Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DNG-200 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Antari DNG-200

Summary of Contents for Antari DNG-200

  • Page 1 DNG-200 LOW FOG GENERATOR USER MANUAL DNG-200 低煙機使用說明書 Read and save these insturctions 2008 Antari Lighting & Effects Ltd.
  • Page 2 ANTARI DNG-200 Low Fog Generator Thank you for choosing this DNG-200 of ANTARI! There are some new terrific features of this machine on top of the fog cooling provided by the DNG-100 originally. The fog generator is integrated into this new machine to make sure the machine will not take too much space in order to maximize the usage of the entire stage.

  • Page 3: Unpacking And Inspection

    7. Three meters of 6mm PU tube 3. Procedures of Installation 3-1. The wheels at the bottom of DNG-200 help to move the machine, wheel fixing mechanisms are located at the diagonal line. Position the machine at a spot, press down the fixing mechanism to prevent it from moving.

  • Page 4: Operation

    4-2. Set all required output modes on the controller. Please refer to D-20 controller operation description. 4-3. DNG-200 is equipped with DMX 512 system, a 3-pin and a 5-pin DMX connectors are located at the back panel of the machine for optional use. Please refer to DMX operation description for more DMX information.
  • Page 5 Sub-menus: Up-/Down-button -->Interval Set -->Duration Set Timer-button -->Volume Out Volume-button -->Nonstop Burst -->High Volume Manual-button -->Medium Volume -->Low Volume -->DMX 512 Add 5-1. Function button 5-1-1. Setting of fog output interval: Press the Function button once, the screen will display “Interval Set”. Under the time counting mode of the timer , press Up/Down keys to adjust the interval of fog output.

  • Page 6: Other Important Notes

    ◄Figure 6 ◄ Figure 7 6-2. DNG-200 is equipped with a pump temperature sensor, when the fog fluid is used up in the tank, pump will stop running due to the rising of the temperature. When the machine temperature drops down, the pump will resume to run. Please check to see if the fog oil is sufficient in the fluid tank.

  • Page 7: Maintenance Of The Machine

    7. Maintenance of the machine 7-1. Please routinely clean your DNG-200 Low Fog Generator, it will effectively help you to lower the parts replacing rate or maintenance cost. 7-2. Please do not contaminate fog oil, put the cap on the oil tank at all time and the cap of the fog oil tank equipped on the machine.
  • Page 8 Antari DNG-200 Built-in DMX 512 Setting DNG-200 is featured with built-in DMX 512 function and equipped with a 3-pin and a 5-pin male-female connectors. When the machine is in use, either 3-pin or 5-pin connector can be selected to connect to DMX controller.
