PRINTHEAD CLEANING
Cleaning of the printhead on a regular basis, preferably in
connection with paper reload, is important for the life of the
printhead and for the printout quality. Below is a description on
how to clean the printhead by means of Cleaning Cards. If
additional cleaning is required, e.g. for removing adhesive
residue from the print roller, dispenser edge, or label path, use
a cotton swab moistened with isopropyl alcohol.
Caution:
Isopropyl alcohol [(CH ) CHOH; CAS 67-63-0] is a highly
3 2
flammable, moderately toxic and mildly irritating substance.
1
2
Open the front and right-hand doors. Turn the printhead lift knob to "Load" position.
3 4
Open the Cleaning Card pouch. The cleaning card
contains isopropyl alcohol, see "Caution" above.
Remove the paper supply.
