Opening the 1800
To open the 1800, you need the following tools:
Small straight slot screwdriver
Pliers or vise
Finger cots or non-powdered latex gloves
To open the 1800
1. Use a small straight slot screwdriver to unclip the two clips at the base of the 1800.
Note: You can expect the clips to break during this procedure, but do not damage
the connector PCB or the bottom shell of the 1800.
2. Use pliers or a vise to squeeze the handle portion of the top shell to break the glue
bond holding the two shells together. Do not squeeze the bottom shell.
Repairing the 1800
1800M011.eps
1800
Vise
1800M044.eps
1
1-7
