Peel-Off , cont.
9
This diagram shows the media and liner
paths.
11
Adjust the position of the green edge
guide so the media is guided with a
minimum of play. Lock with the nut.
Intermec EasyCoder PM4i—User's Guide (IPL version)
Chapter 4—Media Load
10
Turn the printhead lift lever counter-
clockwise to engage the printhead.
12
Adjust the position of the edge guide on
the label slack absorber according to
the width of the media.
27
