Intermec EasyCoder PM4i User Manual page 33

Tear-Off , cont.
1
Open the front and side doors.
3
Pull out the edge guide as far as it
goes and fold it down to a horizontal
position. Remove any empty core from
the media supply roll post.
Intermec EasyCoder PM4i—User's Guide (IPL version)
Chapter 4—Media Load
2
Turn the printhead lift lever clockwise to
raise the printhead.
4
Fit a new roll of media on the supply
post. Fold up and adjust the edge guide
so the roll becomes fl ush with the center
section.
