Installation
Intermec EasyCoder PD4—Service Manual
1 Remove the screw that holds the front cover. Remove the front cover.
2 Open the side door and remove the tear bar, which is held by two Phil-
lips screws.
Screws
3 Attach the cutter mechanism to the printer using the two Phillips screws
and washers included in the kit.
Chapter 10—Cutter
Front cover
Screw
Tear bar
59
