Chapter 2—Front Panels

2.3 Replacing the Front Panel

10
To replace the front panel, follow these steps:
1 Remove the left side panel (see Chapter 3.2).
The electronics compartment contains high voltages wires and circuitry.
Disconnect the power cord to eliminate the risk of electric shock and
short circuits.
Take standard precautions against ESD (Electrostatic Discharges)
before touching any electronics components.
2 Disconnect the fl at cable from the main board.
3 From inside the electronics compartment, remove the two screws that
hold the front panel assembly at the top front of the center section.
4 Lift the front panel assembly up/out so the panel moulding disengages
the two keyholes in the center section.
5 In case of a EasyCoder PD4 with display, disconnect the strip module
cable from CN12 on the main board and remove it from the clips, ties,
and plastic spiral binding.
6 Disconnect the fl at cable from the console pcb.
7 If necessary, replace the entire assembly. Individual items, except the
strip sensor assembly, are not available as spare parts.
8 Install the front panel in reverse order.
