ASSEMBLY

Place all parts of the PROFORM ¨ 975s in a cleared area and remove the packing materials. Do not dispose of
the packing materials until assembly is completed.
Assembly requires the included tools and your own adjustable wrench .
PART CHART
Use the part drawings below to identify the small parts used in assembly. The number in parenthesis below
each drawing refers to the key number of the part. The second number refers to the quantity used in assembly.
Note: Some small parts may have been pre-attached for shipping. If a part is not in the parts bag, check
to see if it has been pre-assembled.
M6 Split Washer (67)Ð4 M10 Split Washer (26)Ð3
M10 Flat Washer (71)Ð4
M6 Nylon Locknut (66)Ð4 M10 Nylon Locknut (72)Ð4 M4 x 16mm Screw (34)Ñ1
#8 x 5/8Ó Screw (22)Ð4 M6 x 16mm Hex Head Screw (24)Ð8 M6 x 25mm Hex Head Screw (14)Ð4
M6 x 38mm Button Head Bolt (18)Ð4 M10 x 25mm Button Head Screw (25)Ð3
M10 x 105mm Button Head Bolt (70)Ð4
