SECTION 6
[CHASSIS PARTS]
REF. NO. ORDER NO.
J1 6510004880 Connector MR-DSE-01
MC1 0800004370 Microphone HM-117B
0800004380 Microphone HM-117W
SP1 2510001040 Speaker F45G07-4
W1 8900007770 Cable OPC-754
8900007930 Cable OPC-773
MP2 8010017264 2040 Chassis-4
MP3 8930045700 2040 IC clip
MP4 8510011530 2040 Case
8510011550 2040 Case (A)
8510011880 2040 Case (B)
8510012510 2040 Case (C)
MP5 8210015210 2040 Front panel
8210015260 2040 Front panel (A)
8210015510 2040 Front panel (B)
8210016230 2040 Front panel (C)
MP6 8930045260 2040 6-KEY
8930046650 2040 6-KEY (A)
MP7 8930045270 2040 R-packing
MP8 8930045280 2040 F-packing
MP10 8610010550 Knob N-264
8610010580 Knob N-264 (A)
MP12 8930033470 1542 Jack bush
MP13 8930045290 2040 Bush plate
MP15 8930014280 SP net
MP16 8810008630 Screw PH B0 M3x6 NI-ZU (BT)
MP17 8810008660 Screw PH B0 M3x8 NI-ZU (BT)
MP18 8810008660 Screw PH B0 M3x8 NI-ZU (BT)
MP19 8810004540 Screw BiH M3x8 SUS
MP20 8810004540 Screw BiH M3x8 SUS
MP21 8810008680 Screw PH M3x8 NI
[LOGIC UNIT]
REF. NO. ORDER NO.
DS1 5030001373 LCD LD-HU4549J-1
DS2 5080000170 Lamp HRS-7219A-Y2 30
DS3 5080000170 Lamp HRS-7219A-Y2 30
W3 8900005320 FFC OPC-519
EP2 8930045650 LCD contact SRCN-2040-SP-N-W
MP1 8210015200 2040 Reflector
MP2 8930045300 2040 LCD holder
[VR-A UNIT]
REF. NO. ORDER NO.
R1 7210001500 Variable resistor RK097111102AA (10KA)
[PWR/VOL] (incl. nut)
[VR-B UNIT ]
REF. NO. ORDER NO.
R1 7210001010 Variable resistor RK097111000AA (10KB)
[SQUELCH] (incl. nut)

MECHANICAL PARTS AND DISASSEMBLY

QTY.
DESCRIPTION
1
[Black] 1
[White] 1
1
[USA] 1
[EUR] 1
1
1
[U-Black] 1
[U-White] 1
[E-White] 1
[E-Black] 1
[U-Black] 1
[U-White] 1
[E-White] 1
[E-Black] 1
[USA] 1
[EUR] 1
1
1
[Black] 2
[White] 2
1
1
1
7
4
2
2
4
4
QTY.
DESCRIPTION
1
1
1
1
1
1
1
QTY.
DESCRIPTION
1
QTY.
DESCRIPTION
1
[MAIN UNIT]
REF. NO. ORDER NO.
MP1 8510011600 2040 VCO Case
MP2 8510011590 2040 VCO Cover
MP3 8510011690 2040 Module plate
8510011860 2040 A-Module plate
[ACCESSORIES]
REF. NO. ORDER NO.
W1 8900006540 Cable OPC-632
MP1 8950004140 1632 MIC hanger
8950004770 1632 MIC hanger (A)
MP2 8010017250 2040 Mobile bracket
8010017270 2040 Mobile bracket (A)
MP3 8610010560 2040 Knob bolt
8610010590 2040 Knob bolt (A)
MP4 8810001470 Screw PH A0 M3.5x30 SUS
MP5 8810001490 Screw PH A0 M5x20 SUS
MP6 8850000180 Flat washer M5 SUS
MP7 8850000500 Spring washer M5 SUS
MP2
W1
Screw abbreviations
6 - 1
DESCRIPTION
[USA]
[EUR]
DESCRIPTION
[U-Black] only
[U-White] only
[Black]
[White]
[Black]
[White]
MP1
MP3
A, B0, BT: Self-tapping
PH: Pan head
FH: Flat head
BiH: Bind head
NI: Nickel
SUS: Stainless
ZK: Black
QTY.
1
1
1
1
QTY.
1
1
1
1
1
2
2
2
2
2
2
MP4
MP5
MP6
MP7
