SECTION 5 PARTS LIST
[LOGIC UNIT]
REF
ORDER
NO.
NO.
IC1
1530007220 S.IC
IC2
1110003500 S.IC
IC3
1130007390 S.IC
IC4
1140005620 S.IC
Q1
1530001950 S.TRANSISTOR 2SC2712-GR (TE85R)
Q2
1510000500 S.TRANSISTOR 2SA1162-GR (TE85R)
Q3
1530001950 S.TRANSISTOR 2SC2712-GR (TE85R)
Q4
1590000670 S.TRANSISTOR FMW1 T148
Q5
1520000450 S.TRANSISTOR 2SB1132 T100 Q
D1
1750000060 S.DIODE
D2
1750000110 S.DIODE
D3
1750000060 S.DIODE
D4
1750000060 S.DIODE
X1
6060000630 S.CERAMIC
R1
7030003560 S.RESISTOR
R2
7030003680 S.RESISTOR
R3
7030003680 S.RESISTOR
R4
7030003680 S.RESISTOR
R5
7030003440 S.RESISTOR
R6
7030003760 S.RESISTOR
R7
7030003720 S.RESISTOR
R8
7030003720 S.RESISTOR
R9
7030003680 S.RESISTOR
R10
7030003620 S.RESISTOR
R11
7030003540 S.RESISTOR
R12
7030003640 S.RESISTOR
R13
7030003560 S.RESISTOR
R14
7030003680 S.RESISTOR
R15
7030003640 S.RESISTOR
R16
7030003640 S.RESISTOR
R17
7030003640 S.RESISTOR
R18
7030000190 S.RESISTOR
R19
7030000190 S.RESISTOR
R20
7030003660 S.RESISTOR
R21
7030003640 S.RESISTOR
R22
7030003630 S.RESISTOR
R23
7030003650 S.RESISTOR
R24
7030003440 S.RESISTOR
R25
7030003510 S.RESISTOR
R26
7030003490 S.RESISTOR
R27
7030003700 S.RESISTOR
R28
7030003640 S.RESISTOR
R29
7030003560 S.RESISTOR
R30
7030003560 S.RESISTOR
R31
7030003640 S.RESISTOR
R32
7030003640 S.RESISTOR
R33
7030003640 S.RESISTOR
R34
7030003640 S.RESISTOR
C1
4030006860 S.CERAMIC
C2
4030006860 S.CERAMIC
C3
4030006900 S.CERAMIC
C4
4030006900 S.CERAMIC
C5
4030006900 S.CERAMIC
C6
4030006900 S.CERAMIC
C7
4030009660 S.CERAMIC
C8
4030006900 S.CERAMIC
C9
4030006900 S.CERAMIC
C10
4510005860 S.ELECTROLYTIC ECEV1HA2R2SR
C11
4030006900 S.CERAMIC
C12
4030006900 S.CERAMIC
C13
4030006900 S.CERAMIC
C14
4030008630 S.CERAMIC
C15
4030008630 S.CERAMIC
C16
4030008630 S.CERAMIC
C17
4030006900 S.CERAMIC
C18
4030006900 S.CERAMIC
[USA]; IC-M45, [EUR]; IC-M45EURO
DESCRIPTION
M38223M4-432-HP FX-2040
S-80742SL-A6-T1
TC7W02F (TE12L)
X25080SI-2.7T6
1SS196 (TE85R)
1SS272 (TE85R)
1SS196 (TE85R)
1SS196 (TE85R)
PBRC 4.91 BR
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 474 V (470 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 333 V (33 kΩ)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
MCR10EZHJ 27 Ω (270)
MCR10EZHJ 27 Ω (270)
ERJ3GEYJ 683 V (68 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 393 V (39 kΩ)
ERJ3GEYJ 563 V (56 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 392 V (3.9 kΩ)
ERJ3GEYJ 272 V (2.7 kΩ)
ERJ3GEYJ 154 V (150 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1E 103K-T-A
C1608 JF 1C 224Z-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1E 103K-T-A
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1E 103K-T-A
[LOGIC UNIT]
REF
ORDER
NO.
NO.
C19
4030006900 S.CERAMIC
C20
4030006900 S.CERAMIC
C21
4030006900 S.CERAMIC
J1
6510019070 S.CONNECTOR 52559-3092
J2
6510018960 S.CONNECTOR B2B-PH-SM3-TB
DS1
5030001373 LCD
DS2
5080000170 LAMP
DS3
5080000170 LAMP
W3
8900005320 FFC
EP1
0910049094 PCB
EP2
8930045650 LCD CONTACT SRCN-2040-SP-N-W
[VR-A UNIT]
REF
ORDER
NO.
NO.
R1
7210001500 VARIABLE
W1
8900007790 CABLE
EP1
0910049102 PCB
[VR-B UNIT]
REF
ORDER
NO.
NO.
R1
7210001010 VARIABLE
EP1
0910049312 PCB
[MAIN UNIT]
REF
ORDER
NO.
NO.
IC1
1110003490 S.IC
IC2
1150001540 IC
IC3
1130007610 S.IC
IC4
1130007370 S.IC
IC5
1130007690 S.IC
IC6
1110003750 S.IC
IC7
1130007700 S.IC
IC8
1180001070 S.IC
IC9
1110003090 IC
IC10
1110003640 S.IC
Q1
1560000550 S.FET
Q2
1580000540 S.FET
Q3
1530002360 S.TRANSISTOR 2SC2714-Y (TE85R)
Q4
1560000330 S.FET
Q5
1560000330 S.FET
Q6
1560000540 S.FET
Q7
1530002600 S.TRANSISTOR 2SC4215-O (TE85R)
5 - 1
DESCRIPTION
C1608 JB 1E 103K-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1E 103K-T-A
LD-HU4549J-1 (E-4548-3)
HRS-7219A-Y2-30
HRS-7219A-Y2-30
OPC-519 (N:30 L:55)
B 5035D
DESCRIPTION
RK097111102AA (10KA)
OPC-759
B 5036B
DESCRIPTION
RK097111000AA (10KB)
B 5055B
DESCRIPTION
TA31136FN (D,EL)
M57710-A/SC-1302
µPD3140GS-E1 (DS8)
TA75S558F (TE85L)
BU4066BCF-T1
M5218AFP 600C
BU4094BCF-T1
TA7805F (TE16L)
LA4425A
BA1604F-T
[USA] only
2SK882-Y (TE85R)
3SK131-T2-LA
2SK210-GR (TE85R)
2SK210-GR (TE85R)
2SK880-Y (TE85R)
S.=Surface mount
