Icom IC-M45 Service Manual page 16

[MAIN UNIT]
REF ORDER
NO. NO.
R89 7030003480 S.RESISTOR
R90 7030003560 S.RESISTOR
R91 7030003480 S.RESISTOR
R92 7030003550 S.RESISTOR
R93 7030003440 S.RESISTOR
R94 7030003770 S.RESISTOR
R95 7030003710 S.RESISTOR
R96 7030003490 S.RESISTOR
R97 7030003380 S.RESISTOR
R98 7030003620 S.RESISTOR
R99 7030003620 S.RESISTOR
R100 7030003480 S.RESISTOR
R101 7030003560 S.RESISTOR
R102 7030003560 S.RESISTOR
R103 7030003640 S.RESISTOR
R104 7030003640 S.RESISTOR
R105 7030003500 S.RESISTOR
R106 7030003580 S.RESISTOR
R107 7030003740 S.RESISTOR
R108 7030003680 S.RESISTOR
R109 7030000100 S.RESISTOR
R111 7030003490 S.RESISTOR
R112 7030003440 S.RESISTOR
R113 7030003730 S.RESISTOR
R114 7030003440 S.RESISTOR
R115 7030003640 S.RESISTOR
7030003690 S.RESISTOR
R116 7030003590 S.RESISTOR
R117 7030003800 S.RESISTOR
R118 7030003670 S.RESISTOR
R119 7030003640 S.RESISTOR
R120 7030003740 S.RESISTOR
R122 7030003670 S.RESISTOR
R123 7030003700 S.RESISTOR
R124 7030003670 S.RESISTOR
R125 7030003670 S.RESISTOR
R126 7030003630 S.RESISTOR
R127 7510000750 S.THERMISTOR NTCCS2012 3NH 103KC-T
R128 7030003570 S.RESISTOR
R129 7030003570 S.RESISTOR
R130 7310002600 S.TRIMMER
R131 7030003550 S.RESISTOR
R132 7030003580 S.RESISTOR
R133 7030003630 S.RESISTOR
R134 7030003320 S.RESISTOR
R135 7030003560 S.RESISTOR
R136 7030003840 S.RESISTOR
R137 7030007590 S.RESISTOR
R138 7030003560 S.RESISTOR
R139 7030003560 S.RESISTOR
R140 7030003400 S.RESISTOR
R141 7030000240 S.RESISTOR
R142 7030003320 S.RESISTOR
R143 7030001070 S.RESISTOR
R144 7030003540 S.RESISTOR
R145 7030003590 S.RESISTOR
R146 7030003280 S.RESISTOR
R147 7030003280 S.RESISTOR
R148 7030003280 S.RESISTOR
R149 7030003280 S.RESISTOR
R150 7030003280 S.RESISTOR
R151 7030003280 S.RESISTOR
R152 7030003520 S.RESISTOR
R153 7030003520 S.RESISTOR
R154 7030003200 S.RESISTOR
R155 7030003300 S.RESISTOR
R156 7030003320 S.RESISTOR
R157 7030003410 S.RESISTOR
C1 4030011160 S.CERAMIC
C2 4030011110 S.CERAMIC
C3 4030011290 S.CERAMIC
C4 4030011070 S.CERAMIC
C5 4030011160 S.CERAMIC
C7 4030011100 S.CERAMIC
C8 4030011260 S.CERAMIC
[USA]; IC-M45, [EUR]; IC-M45EURO
DESCRIPTION
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 822 V (8.2 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 564 V (560 kΩ)
ERJ3GEYJ 184 V (180 kΩ)
ERJ3GEYJ 272 V (2.7 kΩ)
ERJ3GEYJ 331 V (330 Ω)
ERJ3GEYJ 333 V (33 kΩ)
ERJ3GEYJ 333 V (33 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 332 V (3.3 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 334 V (330 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
MCR10EZHJ 4.7 Ω (4R7)
ERJ3GEYJ 272 V (2.7 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 274 V (270 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ) [USA]
ERJ3GEYJ 124 V (120 kΩ) [EUR]
ERJ3GEYJ 183 V (18 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 823 V (82 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 334 V (330 kΩ)
ERJ3GEYJ 823 V (82 kΩ)
ERJ3GEYJ 154 V (150 kΩ)
ERJ3GEYJ 823 V (82 kΩ)
ERJ3GEYJ 823 V (82 kΩ)
ERJ3GEYJ 393 V (39 kΩ)
ERJ3GEYJ 123 V (12 kΩ)
ERJ3GEYJ 123 V (12 kΩ)
RV-110 (RH03A3AS4X0AA) 473
ERJ3GEYJ 822 V (8.2 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 393 V (39 kΩ)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 103 V (10 kΩ)
[USA] only
ERJ3GEYJ 225 V (2.2 MΩ)
[USA] only
RR0816R-433-D (43 kΩ)
[USA] only
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 471 V (470 Ω)
MCR10EZHJ 68 Ω (680)
ERJ3GEYJ 101 V (100 Ω)
MCR50JZHJ 33 Ω (330)
ERJ3GEYJ 682 V (6.8 kΩ)
ERJ3GEYJ 183 V (18 kΩ)
ERJ3GEYJ 470 V (47 Ω)
ERJ3GEYJ 470 V (47 Ω)
ERJ3GEYJ 470 V (47 Ω)
ERJ3GEYJ 470 V (47 Ω)
ERJ3GEYJ 470 V (47 Ω)
ERJ3GEYJ 470 V (47 Ω)
ERJ3GEYJ 472 V (4.7 kΩ)
[USA] only
ERJ3GEYJ 472 V (4.7 kΩ)
[USA] only
ERJ3GEYJ 100 V (10 Ω)
ERJ3GEYJ 680 V (68 Ω)
ERJ3GEYJ 101 V (100 Ω)
ERJ3GEYJ 561 V (560 Ω)
GRM42-6 CH 150J 500PT
GRM42-6 CH 090D 500PT
GRM42-6 CH 240J 500PT
GRM42-6 CH 050C 500PT
GRM42-6 CH 150J 500PT
GRM42-6 CH 080D 500PT
GRM42-6 W5R 102K 500PT
[MAIN UNIT]
REF ORDER
NO. NO.
C9 4030011190 S.CERAMIC
C10 4030007010 S.CERAMIC
C11 4030011220 S.CERAMIC
C12 4030006970 S.CERAMIC
C13 4030009510 S.CERAMIC
C14 4030006860 S.CERAMIC
C15 4030006860 S.CERAMIC
C16 4030006860 S.CERAMIC
C17 4030006860 S.CERAMIC
C18 4030009920 S.CERAMIC
C19 4030006970 S.CERAMIC
C20 4030009570 S.CERAMIC
C21 4030006970 S.CERAMIC
C22 4030006860 S.CERAMIC
C23 4030009510 S.CERAMIC
C24 4030006860 S.CERAMIC
C25 4030006860 S.CERAMIC
C26 4030006960 S.CERAMIC
C28 4030006980 S.CERAMIC
C29 4030006860 S.CERAMIC
C30 4030007110 S.CERAMIC
C31 4030008880 S.CERAMIC
C32 4030006860 S.CERAMIC
C33 4030006860 S.CERAMIC
C34 4030008880 S.CERAMIC
C35 4030006860 S.CERAMIC
C36 4030007010 S.CERAMIC
C37 4030009660 S.CERAMIC
C38 4030006860 S.CERAMIC
C39 4030006900 S.CERAMIC
C40 4030006860 S.CERAMIC
C41 4030008920 S.CERAMIC
C42 4030007130 S.CERAMIC
C43 4030006900 S.CERAMIC
C44 4510004630 S.ELECTROLYTIC ECEV1CA100SR
C45 4030008630 S.CERAMIC
C46 4030008680 S.CERAMIC
C47 4030006900 S.CERAMIC
C50 4030006860 S.CERAMIC
C51 4030006860 S.CERAMIC
C52 4030008630 S.CERAMIC
C53 4030007170 S.CERAMIC
C54 4030007170 S.CERAMIC
C55 4030008630 S.CERAMIC
C56 4030008630 S.CERAMIC
C57 4030006860 S.CERAMIC
C58 4030006860 S.CERAMIC
C59 4550006250 S.TANTALUM
C61 4030009510 S.CERAMIC
C62 4030009910 S.CERAMIC
C63 4030009530 S.CERAMIC
C64 4030009500 S.CERAMIC
C65 4030008920 S.CERAMIC
C67 4030009520 S.CERAMIC
C68 4030009910 S.CERAMIC
C69 4030006860 S.CERAMIC
C70 4550006250 S.TANTALUM
C71 4030009560 S.CERAMIC
C72 4030006860 S.CERAMIC
C73 4030008920 S.CERAMIC
C74 4030006860 S.CERAMIC
C75 4550000730 S.TANTALUM
C76 4030008630 S.CERAMIC
C77 4030008630 S.CERAMIC
C78 4030006860 S.CERAMIC
C79 4030006860 S.CERAMIC
C80 4030009920 S.CERAMIC
C81 4030009990 S.CERAMIC
C82 4030007020 S.CERAMIC
C83 4030006860 S.CERAMIC
C84 4030007040 S.CERAMIC
C85 4030006860 S.CERAMIC
C86 4030006860 S.CERAMIC
C87 4030007010 S.CERAMIC
C88 4030006860 S.CERAMIC
C89 4030006860 S.CERAMIC
C90 4030007040 S.CERAMIC
C91 4030006860 S.CERAMIC
C92 4030006860 S.CERAMIC
C93 4030006860 S.CERAMIC
C94 4030007020 S.CERAMIC
C95 4030006860 S.CERAMIC
5 - 3
DESCRIPTION
GRM42-6 CH 270J 500PT
C1608 CH 1H 100D-T-A
GRM42-6 CH 360J 500PT
C1608 CH 1H 060D-T-A
C1608 CH 1H 010B-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 CH 1H 050B-T-A
C1608 CH 1H 060D-T-A
C1608 CH 1H 0R3B-T-A
C1608 CH 1H 060D-T-A
C1608 JB 1H 102K-T-A
C1608 CH 1H 010B-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 CH 1H 050C-T-A
C1608 CH 1H 070D-T-A
C1608 JB 1H 102K-T-A
C1608 CH 1H 680J-T-A
C1608 JB 1C 223K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1C 223K-T-A
C1608 JB 1H 102K-T-A
C1608 CH 1H 100D-T-A
C1608 JF 1C 224Z-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1C 473K-T-A
C1608 CH 1H 101J-T-A
C1608 JB 1E 103K-T-A
C1608 JF 1C 104Z-T-A
C2012 JF 1C 105Z-T-A
C1608 JB 1E 103K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JF 1C 104Z-T-A
C1608 CH 1H 221J-T-A
C1608 CH 1H 221J-T-A
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
TEMSVA 1A 106M-8L
C1608 CH 1H 010B-T-A
C1608 CH 1H 040B-T-A
C1608 CH 1H 030B-T-A
C1608 CH 1H 0R5B-T-A
C1608 JB 1C 473K-T-A
C1608 CH 1H 020B-T-A
C1608 CH 1H 040B-T-A
C1608 JB 1H 102K-T-A
TEMSVA 1A 106M-8L
C1608 CH 1H R75B-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1C 473K-T-A
C1608 JB 1H 102K-T-A
TESVA 0J 225M1-8L
C1608 JF 1C 104Z-T-A
C1608 JF 1C 104Z-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 CH 1H 050B-T-A
C1608 CH 1H 200J-T-A
C1608 CH 1H 120J-T-A
C1608 JB 1H 102K-T-A
C1608 CH 1H 180J-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 CH 1H 100D-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 CH 1H 180J-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 JB 1H 102K-T-A
C1608 CH 1H 120J-T-A
C1608 JB 1H 102K-T-A
S.=Surface mount
