Valcom V-5335405 Specification page 2

Note: The shielding for the wires should NOT be
connected to the GND screw at any microphone
in the star configuration.
Note: The Shield should remain continuous to the
end of the wire run and should only be grounded
at the amplifier.
Figure 6 shows the wiring diagram for connecting
microphones to a Paging Controller Unit.
TOUCHTONE PAD FOR
MULTI-ZONE ACESS
LED INDICATORS
Figure 1. Multi-Zone Microphone Features
TECHNICAL ASSISTANCE
When calling, have a VOM and a telephone test
set available and call from the job site. Call (540)
427-3900 and ask for PagePac Technical Sup-
port, or call (540) 427-6000 for Valcom 24-hour
Automated Support or visit our websites at
http://www.pagepac.com and www.valcom.com.
Should repairs be necessary, attach a tag to the
unit clearly stating company name, address,
phone number, contact person, and the nature of
the problem. Send the unit to:
Valcom, Inc.
PagePac
5614 Hollins Road
Roanoke, VA 24019-5056
CARDIOID ELECTRET
CONDENSER ELEMENT
WITH HIGH SUPPRESSION
OF BACKGROUND NOISE
MOMENTARY PUSHBUTTON
FOR SHORT PAGES
LOCKING PUSHBUTTON
FOR LONG PAGES
2
®
Repair Dept.
947189
