Valcom PagePac 6 Plus Manual

Valcom PagePac 6 Plus Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

PagePac
by

TABLE OF CONTENTS

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-2
Important Safety Instructions . . . . . . . . . . . . . . . . . 2-3
General Information . . . . . . . . . . . . . . . . . . . . . . . . . 3
Two Telephone Lines . . . . . . . . . . . . . . . . . . . . . . . 3-4
Options -- And How to Select Them . . . . . . . . . . . 6-7
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Technical Assistance . . . . . . . . . . . . . . . . . . . . . . . .11
FCC Regulations / CSA Information . . . . . . . . . 12-13
Secondary Circuit Protection . . . . . . . . . . . . . . . 13-14

INTRODUCTION

®
PagePac
6 Plus is a compact, 6-watt, voice-paging system that integrates three paging zones, each
with talkback capability, into your telephone system. PagePac 6 Plus can be used with most telephone
systems, from single-line residential systems to electronic key and PBX systems.

SPECIFICATIONS

FEATURES
• Works with either one or two lines, and provides two separate paging accesses when used with two
lines
• Provides three separate paging zones, each with a 2-watt output, as well as "all call" paging and zone
groups
• Talkback is available in all three zones
• Supports both standard (indoor) and horn (outdoor) speakers.
Compatible with voice coil speakers only.
• FCC and CSA approved
• Controls background music in all three zones (music must be provided from a separate source, such
as an external music source, FM tuner, a tape deck, or leased source). See Note.
• Comes with its own 12-VAC power supply and plugs into any standard 120-VAC, 60 Hz outlet
• User options are telephone dial selected (DTMF or Pulse)
Technical Manuals Online! - http://www.tech-man.com
Technical Manuals Online! - http://www.tech-man.com
®
PAGEPAC 6 PLUS
firealarmresources.com
V-5323008
1
Issue 1
947182

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PagePac 6 Plus and is the answer not in the manual?

Questions and answers

Related Manuals for Valcom PagePac 6 Plus

Summary of Contents for Valcom PagePac 6 Plus

  • Page 1: Table Of Contents

    6 Plus is a compact, 6-watt, voice-paging system that integrates three paging zones, each with talkback capability, into your telephone system. PagePac 6 Plus can be used with most telephone systems, from single-line residential systems to electronic key and PBX systems.

  • Page 2: Important Safety Instructions

    Note: Those who use paging systems to rebroadcast copyrighted music are required to obtain licenses from and pay fees to copyright owners. This usually involves obtaining licenses and paying fees to either ASCAP and/ or BMI (American Society of Composers, Artists and Producers, Broadcast Music Inc.). It is the user's obligation to obtain any license required and pay any fees.

  • Page 3: General Information

    3. Never touch uninsulated telephone wires or terminals unless the telephone line has been disconnected at the network interface. 4. Use caution when installing or modifying telephone lines. INSTALLING THE PAGEPAC 6 PLUS WITH ONE OR TWO TELEPHONE LINES Figure 1. PagePac 6 Plus -- Typical Installation 947182 Technical Manuals Online! - http://www.tech-man.com...
  • Page 4 4. (Optional) You may connect an external music source such as a FM tuner, tape deck, leased source, etc. 5. Connect the power supply to an AC outlet (120 VAC, 60 Hz). The LED on the PagePac 6 Plus back panel (below the power cord) will illuminate.

  • Page 5: Connecting Speakers To Pagepac 6 Plus

    300 Feet Run (24 AWG Wire) *A run is a line of one or more speakers that connects directly to PagePac 6 Plus. NOTE: If using both horns and standard speakers in the same zone, each horn counts as six standard speakers.

  • Page 6: Options -- And How To Select Them

    OPTIONS -- AND HOW TO SELECT THEM You may select the following options for your PagePac 6 Plus. • Zone Paging—PagePac 6 Plus has three separate paging zones. Each zone is a specific group of speakers in which the page will be heard. •...
  • Page 7 Setting Options To select the desired option, dial the code shown. 1. Pick up the telephone and listen for PagePac 6 Plus dial tone (on key systems, select the desired line first). 2. Dial the number for the option desired (see Table 2 or the simplified user guide supplied), and listen for program tone (two short tones).

  • Page 8: Tones You Hear -- And What They Mean

    Note: To dial emergency 911, dial 9 or wait for the regular dial tone, and then dial 911. 3. Dial the number. Dialing 9 gives you regular dial tone immediately. If you wait, PagePac 6 Plus will time out and then provide regular dial tone. How long this takes depends on which Automatic 947182 Technical Manuals Online! - http://www.tech-man.com...
  • Page 9 USING LAST NUMBER REDIAL WITH PAGEPAC 6 PLUS If your telephones have last number redial, you can use it with PagePac 6 Plus. The exact procedure depends on whether or not your phone has a PAUSE button.

  • Page 10: How To Adjust Page, Talkback And Music Volume

    The PagePac® 6 Plus contains no user-serviceable parts, and should be repaired only by authorized personnel. There are several types of installation and maintenance plans available from Valcom or your dealer. For information or warranty service, call your Valcom sales representative or authorized dealer.

  • Page 11: Troubleshooting

    When calling, have a VOM and a telephone test set available and call from the job site. Call (540) 427-3900 and ask for PagePac Technical Support, or call (540) 427-6000 for Valcom 24-hour Automated Support or visit our websites at http://www.pagepac.com and www.valcom.com.
  • Page 12 Relocate the PagePac 6 Plus with respect to the radio or TV receiver or vice-versa. • Plug the PagePac 6 Plus into a different outlet so that it and the radio or TV receiver are on different branch circuits. •...

  • Page 13: Fcc Regulations / Csa Information

    CSA INFORMATION The Canadian equivalent of the RJ11C connector is CA11A. Where applicable, CA11A is to be under- stood for other references to RJ11C in this manual. This product is CSA Certified. In Canada, the DOC registration number appears on the maple-leaf label, and the Load Number is under the maple-leaf label.

  • Page 14: Secondary Circuit Protection

    • Use caution when installing or modifying telephone lines. • Use appropriate Valcom approved device. Figure 7. Example Configurations Requiring Secondary Protection When Paging Equipment is Connected Directly to the Telephone Network 947182 Technical Manuals Online! - http://www.tech-man.com Technical Manuals Online! - http://www.tech-man.com...
