Specifications - Polycom CX400 Specifications

Polycom CX400 Cordless Phone
Size (H x W x D)
• Handset: 5.55 x 1.85 x 0.83 in (141 x 47 x 21 mm)
• Cradle: 1.77 x 2.76 x 2.76 in (45 x 70 x 70 mm)
Weight
• Handset: 3.6/2.9 ounces (103/82 g) with/without battery
• Cradle: 2.7 ounces (77 g)
• Shipping Weight: 14.3 ounces (406 g)
Power
• Supply voltage: 5.0 V (supplied by USB connector)
• Operating voltage: 3.4 – 5.0 V
• Power consumption 70 – 80 mA
Handset Battery
• Lithium Polymer, 900mA
• Up to 10 hours talk time when fully charged
Cradle-to-PC Interface
• USB 2.0
Cradle – Handset Radio
• 2.4 GHz ISM band
- Typical Range: 33 ft (10m)
Handset Controls and Keypad
• Call Pick-up key
• Mute/Unmute key
• Speaker on/off key
• Hang-up/Power on/off key
• Volume up/down key (Microsoft PowerPoint slideshow next/previous key when in
slideshow controller mode)
• Phone/PowerPoint mode selector switch
Handset Screen
• 1.77 inch
• 128 x 160 pixels with 262 colors
LED Indicators
• Handset: combined dual-color battery status/power indicator
• Cradle
- Power/charging indicator
- Link status indicator
Audio
• Frequency response: 30 – 20kHz
• Signal-to-noise ratio: 78 dB (@ 1kHz)
• Dynamic range: >80 dB (@ 1kHz)
• Total Harmonic Distortion + Noise: <0.08% (@ 1kHZ)
• Output power: 15/30 mW (into 32/16 ø load)
• Output level: 700 mV
Auxiliary Audio Output
• 2.5 mm jack for mobile phone-type headset*
• Speakerphone mode directs audio output to PC's speakers
Audio Enhancements
• Automatic Gain Control
• Dynamic Noise Reduction
Polycom Headquarters:
www.polycom.com
Polycom EMEA:
Polycom Asia Pacific:

Specifications

Minimum System Requirements
• PC with Office Communicator 2007 installed
• Windows XP or Windows Vista
• One available USB port
Environmental Requirements
• Operating
- Temperature: 40° – 95° F (5° – 35° C)
- Relative humidity: 20% – 85% (noncondensing)
• Storage
- Temperature: 15° – 140° F (-10° – 60° C)
- Relative humidity: 10% – 85% (noncondensing)
Regulatory Compliance – Approvals Gained
• Battery Safety
- UL2054
• Electrical Safety
- UL60950-1
- IEC/EN60950-1
• EMC (Class B)
- FCISPR 22: 2005
- FCC CFR Title 47 Part 15 Subpart B:2005 (US)
- ANSI C63.4: 2003 (US)
- ICES 003: 1998 (Canada)
- EN 55022:1998+A1:+A2: (EU)
- EN61000-3-2:2000+A2: (EU)
- EN61000-3-3:1995+A1:+A2: (EU)
- EN 55024:1998+A1:+A2: (EU)
- VCCI (Japan)
• RF
- FFCC CFR Title 47 Part 15.247 (US)
- RSS 210 Issue 7: 2007 (Canada)
- RSS Gen Issue 2: 2007 (Canada)
- EN 300 328:V1.6.1 (2004-11) (EU)
- EN 301 489-1:V1.6.1 (2005-09) (EU)
- EN 301 489-17:V1.2.1 (2002-08) (EU)
- ACIF STD-T66 (Japan)
• Additional Compliance
- CQC (China)
Warranty
• 12 months
Polycom CX400 Cordless Phone Ships With:
• Polycom CX400 Cordless Phone handset
• Handset Lithium Polymer battery
• Handset battery cover
• Docking cradle with integrated USB cable
• Quickstart Guide
• Warranty card
* Available headset audio performance may be less than that of the CX400 cordless phone.
©2007 Polycom, Inc. All rights reserved.
Polycom and the Polycom logo are registered trademarks of Polycom, Inc. in the U.S. and various countries.
All other trademarks are the property of their respective owners. Information in this document is subject to change without notice.
4750 Willow Road, Pleasanton, CA 94588 (T) 1.800.POLYCOM (765.9266) for North America only.
For North America, Latin America and Caribbean (T) +1.925.924.6000, (F) +1.925.924.6100
270 Bath Road, Slough, Berkshire SL1 4DX, (T) +44 (0)1753 723000, (F) +44 (0)1753 723010
8 Shenton Way, #11-01 Temasek Tower, Singapore 068811 (T) +65.6389.9200, (F) +65.6323.3022
Part No. 3726-17816-001 Rev. 10/07
