ZvBox 150 Specifications
Video Input
Computer VGA (Analog)
HD‐15 connector, buffered and looped
Resolutions Supported:
640x480, 720x480, 800x600,
1024x768, 1152x864, 1176x664,
1280x720, 1280x768, 1280x800,
1280x960, 1280x1024, 1360x768,
1440x900 at 60,70,72,75, 85 Hz.
1680x1050 at 60 Hz
Component Video (Y, Pr, Pb)
RCA connectors
Resolutions Supported:
480i 60 fields per second
480p 60 frames per second
720p 60 frames per second
Audio Input
SPDIF Digital Audio
Physical Connections
TOSLINK optical, RCA and USB
Formats
48K bit PCM
AC‐3 Pass‐through
Video Encoder
Encoder Video Profile
MPEG2 HD Profile 2: ISO13818‐2
MP@HL (1280x720)
Video Transport Bit Rate 38.78 Mbps
ZvBox www.zeevee.com
Zv150_GGG_v1_0 Zv150_GGG_v1.1
Average Encoding Data Rate 14 Mbps
Program Information – Programmable
Content Watermarking – Digital and
Visual
Audio Encoder
Encoder Audio Profile
Dolby Digital® AC‐3
ATSC A/52
Digital Pass‐through
Dolby Digital® (AC‐3) 1‐5.1 channel,
Linear PCM
RF Spectrum Analysis
This page left intentionally blank.
Able to scan all 135 coax cable channels
and report the usage of each
Analog / Digital or Empty channel
STD / HRC / IRC detection
Modulator / Upconverter
Modulation Types
QAM 256 (ITU‐T J83 Annex B)
Cable Standard
HRC, IRC or STD
Frequency Range
50 – 900 MHz (channels 2‐141)
Output Power
+25 dBmV typical
Output Level Adjust
0 – 20 dB of attenuation in 5dB steps
Control / Setup
Powerful command line interface ‐ USB
Input Switching ‐ IR or USB
General
Power ‐ 100VAC to 240VAC, 50/60 Hz,
<20watts
Cooling – Convective. Cannot be stacked
or put above other hot components.
Mounting ‐ Counter or shelf
Enclosure type ‐ Metal
Enclosure dimensions
1.38" H x 11.42" W x 4.02" D
35mm H x 290mm W x 102mm D
Weight
1.21 lbs (550 grams)
Temperature/Humidity
Operating +32° to +95°F (0° to +35°C) /
20% to 80%, non‐condensing
MTBF – 30,000 hours
Compliance
Safety UL60065
FCC Class B
Part number ‐ ZV150‐NA
Model name ‐ ZvBox 150
Warranty ‐ 1 year
