QTY
4 Zip ties
2 Hose clamps (2 ¾" diameter)

3.2 Recommend Tools

•
Precision screwdriver (for small Phillips screws)
•
Pliers
•
Phillips screwdriver
•
Flat blade screwdriver
•
Tack (small) hammer or rubber mallet
•
Compass or GPS (for wind direction calibration)

3.3 Sensor Assembly Set Up

1. Connect the wind cup assembly to either end of the anemometer mounting arm. Align the
holes, and fasten with long bolt and nut. Tighten with precision screwdriver while securing
the nut with pliers, as shown in Figure 1.
Version 1.10
Figure 1
©Copyright 2011, Ambient LLC. All Rights Reserved.
Item
Page 4
