Model: SFE-35
INSTALLER/CONSUMER SAFETY
INFORMATION
PLEASE READ THIS MANUAL BEFORE
INSTALLING AND USING APPLIANCE.
WARNING!
IF THE INFORMATION IN THIS
MANUAL IS NOT FOLLOWED
EXACTLY, AN ELECTRICAL SHOCK
OR FIRE MAY RESULT, CAUSING
PROPERTY DAMAGE, PERSONAL
INJURY OR LOSS OF LIFE.

FOR YOUR SAFETY

SERVICE MUST BE PERFORMED BY
A QUALIFIED SERVICE AGENCY.
DO NOT STORE OR USE GASOLINE
OR OTHER FLAMMABLE VAPORS
AND LIQUIDS IN THE VICINITY OF
THIS OR ANY OTHER APPLIANCE.
ANSI / UL 2021. Fixed or location dedicated electric room heater.
Installer: do not discard this manual -- leave for home owner
1
US
C
BUILDER BOX
TUV Listed as SFE-35
Homeowner's Installation & Operating Manual
Note:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Simplifyre SFE-35 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hearth and Home Technologies Simplifyre SFE-35

Summary of Contents for Hearth and Home Technologies Simplifyre SFE-35

  • Page 1: For Your Safety

    Model: SFE-35 BUILDER BOX INSTALLER/CONSUMER SAFETY INFORMATION PLEASE READ THIS MANUAL BEFORE INSTALLING AND USING APPLIANCE. WARNING! IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED EXACTLY, AN ELECTRICAL SHOCK OR FIRE MAY RESULT, CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. FOR YOUR SAFETY TUV Listed as SFE-35 SERVICE MUST BE PERFORMED BY...

  • Page 2: Table Of Contents

    Congratulations! TABLE OF CONTENTS 1 Important Instructions Fireplace Dimensions Operating Instructions Electrical Wiring Service Instructions Replacement Parts List Warranty...

  • Page 3: Important Instructions

    Important Instructions WARNING! Risk of Fire! WARNING! Improper installation, adjustment, altera- tion, service or maintenance can cause injury or prop- DO NOT: erty damage. NOTICE! WARNING! Risk of Electric Shock! electrical code. materials in this heater. damage. coil cord.
  • Page 4 A Unpacking the Unit F. Hardwire Electrical Connections WARNING! Do NOT use this appliance if any part has WARNING! Electrical wiring must comply with local been under water. building codes and other applicable regulations to reduce the risk of re, electrical shock and injury. Note: nishing the B.

  • Page 5: Fireplace Dimensions

    Fireplace Dimensions 22 in. 55.9 cm 12.5 in. Unit Top 31.8 cm 35 in. 88.9 cm 33.6 in. 85.4 cm Unit Front 30.5 in. 77.5 cm Note: Nailing flanges may be hand-bent to accommodate framing for different styles of optional decorative fronts.

  • Page 6: Operating Instructions

    OPERATING INSTRUCTIONS A. Remote Control Note: B. Remote Control Initialization screen. Learn Button C. Control Usage transmitter. FLAMES transmitter. HEATER...

  • Page 7: Electrical Wiring

    Electrical Wiring Interlock on Lamp Media Cabinet only Projector Remote Receiver Motor Flame Power Supply Module Heat Flame 4050-309 Terminal Strip Wall Switch Heat Hot Line NEMA-5 IEC 320 C13/C14 12 VOC Ground Power Supply Neutral Branch Circuit Ember Bed & Back Log 4050-310 Wall Thermostat LED LED LED...

  • Page 8: Replacement Parts List

    E. Optional Wall Switch / Thermostat Wiring Connections instructions To control the replace with a single switch: To control ames/ember bed with one switch and heater/front embers with another switch: To control ames/ember bed with a switch, and control the heater with a thermostat:...

  • Page 9: Warranty

    Warranty How to Obtain Service. ADDITIONAL INFORMATION.
