MODEL: SFE-26
INSTALLER / CONSUMER
SAFETY INFORMATION
PLEASE READ THIS MANUAL
BEFORE INSTALLING AND
USING APPLIANCE
WARNING
IF THE INFORMATION IN THIS
MANUAL IS NOT FOLLOWED
EXACTLY, AN ELECTRICAL
SHOCK OR FIRE MAY RESULT,
CAUSING PROPERTY DAMAGE,
PERSONAL INJURY OR LOSS
OF LIFE
ANSI / UL 2021. FIXED OR LOCATION DEDICATED ELECTRIC ROOM HEATER.
INSTALLER: DO NOT DISCARD THIS MANUAL— LEAVE FOR HOME OWNER
4050-308 Rev A 9/13/2007
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
BUILDER BOX
TUV LISTED AS SFE-26
Homeowner's Installation &
Operating Manual
NOTE: The device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1.
This device may not cause harmful
interference, and
2.
This device must accept any interference
received, including interference that may cause
undesired operation.
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Hearth and Home Technologies Simplifyre SFE-26
Summary of Contents for Hearth and Home Technologies Simplifyre SFE-26
- Page 1 MODEL: SFE-26 BUILDER BOX INSTALLER / CONSUMER SAFETY INFORMATION PLEASE READ THIS MANUAL BEFORE INSTALLING AND USING APPLIANCE WARNING IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED EXACTLY, AN ELECTRICAL SHOCK OR FIRE MAY RESULT, CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE TUV LISTED AS SFE-26 Homeowner’s Installation &...
-
Page 2: Table Of Contents
Congratulations! Congratulations on selecting a Simplifyre electric fireplace. The unit you have selected is designed to provide the utmost in safety, reliability and efficiency. As the owner of a new fireplace, you’ll want to read and carefully follow all of the instructions contained in this owner’s manual. -
Page 3: Important Instructions
IMPORTANT INSTRUCTIONS • When using electrical heaters, basic precautions should To prevent a possible fire, do not block air intakes or always be followed to reduce the risk of fire, electric shock exhaust in any manner. • injury to persons, including the following: An heater has hot and arcing or sparking parts inside. -
Page 4: Unpacking
ELECTRICAL SPECIFICATIONS UNPACKING THE UNIT Voltage: 120 V AC, 60 Hz WARNING Total Amps: 11.25 AMP Do not use this fireplace if any part of it has been Total Watts: 1350 Watts under water. Immediately call a qualified service Heater Rating: 1300 Watts/4415 BTU technician to inspect and replace any of the electrical system if necessary. -
Page 5: Framing Dimensions
FIREPLACE DIMENSIONS NOTE: Provide allowance for raised hearth or mantle. This unit mounts flush to the floor surface. Fig. 1 FIREPLACE SPECIFICATIONS AND FRAMING DIMENSIONS Ref. inch 26 3/4 67.9 27 1/4 69.9 18 5/8 46.7 101.6 45.7 22 3/4 57.8 FRAMING DIMENSIONS 23 1/4... -
Page 6: Operating Instructions
OPERATING INSTRUCTIONS Ensure the appliance is connected to a properly grounded electrical outlet on a minimum 15 AMP circuit. If a new outlet is required, it should be installed by a qualified electrician according to applicable building codes. REMOTE CONTROL NOTE: if the fireplace does not respond to the hand held control see “Remote Control Initialization”... -
Page 7: Electrical Wiring Diagram
ELECTRICAL WIRING SERVICE INSTRUCTIONS WARNING SCREEN CLEANING Disconnect power at circuit breaker before attempting any maintenance or cleaning to reduce the risk of fire, electrical During shipment, installation, handling, etc., the shock or personal injury. screen surface may collect dust particles; these can be removed by lightly wiping with a clean, dry cloth. -
Page 8: Replacement Parts List
Replacement Parts List 1. Smoke Shield 4050-301 2. Back Log 4050-302 3. 120V Heater Assembly 4050-304 4. SFE-26 Installation Manual 4050-308 5. Remote Receiver 4050-108 6. Front Log/Emberbed Assembly 4050-300 7. Remote Transmitter 4050-105 8. Power Input Assembly 4050-005 9. Power Assembly 4050-305 10. -
