INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
NOTICE: DO NOT discard this manual!
Models:
DV3732
DV3732L
DV4236
This appliance may be installed as an OEM
installation in manufactured home (USA
only) or mobile home and must be installed
in accordance with the manufacturer's
instructions and the Manufactured Home
Construction and Safety Standard, Title 24
CFR, Part 3280 in the United States, or the
Standard for Installation in Mobile Homes,
CAN/CSA Z240 MH Series, in Canada.
This appliance is only for use with the type(s)
of gas indicated on the rating plate. This
appliance is not convertible for use with other
gases, unless a certifi ed kit is used.
Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16
Installation Manual
Installation and Appliance Setup
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly
could result in serious injury, death, or
property damage.
• DO NOT store or use gasoline or other fl am-
mable vapors and liquids in the vicinity of this
or any other appliance.
• What to do if you smell gas
- DO NOT try to light any appliance.
- DO NOT touch any electrical switch. DO
NOT use any phone in your building.
- Leave the building immediately.
- Immediately call your gas supplier from
a neighbor's phone. Follow the gas sup-
plier's instructions.
- If you cannot reach your gas supplier, call
the fi re department.
• Installation and service must be performed
by a qualifi ed installer, service agency, or the
gas supplier.
DANGER
DO NOT TOUCH GLASS
NEVER ALLOW CHILDREN
A barrier designed to reduce the risk of
burns from the hot viewing glass is provided
with this appliance and shall be installed for
the protection of children and other at-risk
individuals.
In the Commonwealth of Massachusetts installation must be
performed by a licensed plumber or gas fi tter.
See Table of Contents for location of additional Commonwealth
of Massachusetts requirements.
HOT GLASS WILL
CAUSE BURNS.
UNTIL COOLED.
TO TOUCH GLASS.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DV3732 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hearth and Home Technologies DV3732

  • Page 1 See Table of Contents for location of additional Commonwealth gases, unless a certifi ed kit is used. of Massachusetts requirements. Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 2: Table Of Contents

    B. Securing and Leveling the Appliance ....34  = Contains updated information. Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 3: Installation Standard Work Checklist

    _________________________________________________________________________________________________ Comments Communicated to party responsible ____________________ by ______________________on ___________ (Builder / Gen. Contractor/) (Installer) (Date) = Contains updated information. 2355-982 Rev. D 2/16 Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 4: Product Specifi C And Important Safety Information

    Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 5: Requirements For The Commonwealth Of Massachusetts

    VENT DIRECTLY BELOW. KEEP CLEAR OF ALL OB- of the installation. STRUCTIONS”. See Gas Connection section for additional Common- wealth of Massachusetts requirements. Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 6: Getting Started

    30 degrees or more depending on the thermometer settings and/or gas control which has been under water. and material characteristics being measured. Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 7: Framing And Clearances

    Millimeters Location Inches Millimeters 16-5/16 31-1/8 29-7/16 25-3/4 12-7/8 34-5/16 15-7/8 6-5/8 6-7/8 2-3/8 2-3/16 36-1/4 1-1/16 8-13/16 Figure 3.1 Appliance Dimensions - DV3732 Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 8 8-13/16 36-1/8 16-5/16 32-1/16 21-1/2 30-3/4 37-5/8 15-3/8 3-9/16 15-7/8 6-7/8 6-5/8 26-7/8 2-3/16 37-7/8 39-15/16 1014 33-9/16 Figure 3.2 Appliance Dimensions - DV4236 Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 9 25-7/8 30-15/16 2-3/16 1-1/2 27-1/4 28-3-/4 SRV2355-021 DV4236 DECORATIVE FRONT  35-13/16 31-1/8 34-3/8 29-5/8 32-1/2 2-1/8 1-5/16 SRV2298-056 Figure 3.3 Decorative Front Dimensions Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 10: Clearances To Combustibles

    See Section 10.B for Alcove Installation 45-1/2 64-3/8 45-1/2 64-3/8 16-1/4 48-1/2 68-3/4 16-5/8 7-1/2 DV4236 1156 1067 1635 1156 1635 1232 1746 Figure 3.4 Appliance Locations Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 11: Constructing The Appliance Chase

    * Adjust framing dimensions for interior sheathing (such as sheetrock) C** Add 12 inches for rear venting with one 90º elbow. Figure 3.5 Clearances to Combustibles Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 12: Termination Location And Vent Information

    Over 20/12 to 21/12 ..........8.0 * H minimum may vary depending on regional snowfall. Refer to local codes. Figure 4.1 Minimum Height From Roof To Lowest Discharge Opening Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 13: Chimney Diagram

    • Vinyl protection kits are suggested for use with vinyl siding. Figure 4.3 Minimum Clearances for Termination Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 14: Approved Pipe

    WARNING! Risk of Fire or Asphyxiation. This appli- ance requires a separate vent. DO NOT vent to a pipe serving a separate solid fuel burning appliance. Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 15: Use Of Elbows

    DVP36 25-1/2 DVP48 1219 DVP6A 3 to 6 76 to 152 2-1/8-4-1/4 54-108 DVP12A 3 to 12 76 to 305 2-1/8-8-1/2 54-216 Figure 4.4 Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 16: Measuring Standards

    However, 1 in. the vent attachment point and the fi restop CLEARANCE location are considered to be supports. Figure 4.6 Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 17: Vent Diagrams

    Note: There MUST be a 25% reduction in total H when using fl ex vent except when using the simple up and out installation (see Figure 4.6). Figure 4.7 Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 18 • When using DVP-TB1 termination cap on top vented fi replaces, a three foot minimum vertical vent section is required before installing fi rst elbow. Figure 4.8 Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 19 • When using SLP-HRC-SS termination cap on top vented fi replaces, a one foot minimum vertical vent section is required before installing fi rst elbow. Figure 4.9 Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 20 Figure 4.11 a total vertical of 15-60 feet, an exhaust restrictor may be needed. The exhaust restrictor can be located in the appliance manual bag. Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 21 Note: There MUST be a 25% reduction in total H when using fl ex vent except when using the simple up and out installation (see Figure 4.6). Figure 4.13 Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 22 Note: There MUST be a 25% reduction in total H when using fl ex vent except when using the simple up and out installation (see Figure 4.6). Figure 4.14 Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 23 Note: Use DVP Series components only. Figure 4.15 = 9 in. (229 mm) Maximum One 45º Elbow Note: Use DVP Series components only. Figure 4.16 Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 24 13-1/2 ft. 4.1 m HORIZONTALLY MAX. = 7-1/2 ft. (2.3 m) MAX. = 13-1/2 ft. (4.1 m) MAX. = 40 ft. (12.2 m) Figure 4.18 Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 25 3 ft. 914 mm H MAX. = 6-1/2 ft. (2 m) V + H+ H MAX. = 40 ft. (12.2 m) INSTALLED HORIZONTALLY Figure 4.20 Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 26 MAX. = 7-1/2 ft. (2.3 m) MAX. = 14-1/2 ft. (4.4 m) MAX. = 40 ft. (12.2 m) Note: Use DVP Series components only. Figure 4.21 Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 27 CAUTION! DO NOT use any fl ue restrictor when vent- ing with the DV-46DVA-GCL adapter and LINK-DV30B kit. This could result in poor fl ame appearance, sooting, pilot malfunction, or overheating. Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 28 0 ft. 0 mm Minimum 10 ft. 3.05 m Maximum 40 ft. 12.2 m 2 ft. 610 mm Maximum 40 ft. 12.2 m Figure 4.24 Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 29: Vent Clearances And Framing

    Top: 2-1/2 in. (64 mm) Bottom: 1/2 in. (13 mm) Sides: 1 in. (25 mm) Figure 5.1 Horizontal Venting Clearances To Combustible Materials Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 30: Wall Penetration Framing/Firestops

    * Shows center of vent framing hole for top or rear venting. The center of the hole is one (1) in. (25.4 mm) above the center of the horizontal vent pipe. Figure 5.2 Wall Penetration Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 31: Ceiling Firestop/Floor Penetration Framing

    INSTALL ATTIC INSULATION SHIELDS BEFORE OR AFTER INSTALLATION OF VENT SYSTEM CEILING FIRESTOP CEILING FIRESTOP INSTALLED BELOW CEILING INSTALLED ABOVE CEILING Figure 5.4 Installing the Attic Shield Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 32: Appliance Preparation

    The heat shield must remain in the vertical position. 2 SCREWS Figure 6.3 Replace the two screws as shown. Figure 6.6 Remove the insulation from the outer vent pipe. Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 33: Rear Vent

    Use two self- tapping screws to secure gasket to outer wrap. Figure 6.9 Cut the metal retaining band and fold the sides out. Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 34: Securing And Leveling The Appliance

    DV3732 DV4236 NAILING TABS BOTH SIDES NAILING TABS (BOTH SIDES) Figure 6.13 Proper Positioning, Leveling And Securing Of An Appliance Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 35: Venting And Chimneys

    Use screws no longer than 1/2 INCORRECT in. (13 mm). If predrilling screw holes, DO NOT penetrate Figure 7.4 Seams inner pipe. Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 36: Assemble Slip Sections

    • All unit collar, pipe, slip section, elbow and cap outer Figure 7.5 Adding Venting Components fl ues shall be sealed. Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 37: Secure The Vent Sections

    120º Figure 7.11 Align and Disassemble Vent Sections Figure 7.8 Securing Vertical Pipe Sections 120º Figure 7.9 Securing Horizontal Pipe Sections Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 38: Vertical Termination Requirements

    • Caulk the perimeter of the fl ashing where it contacts the roof surface. See Figure 7.13. • Caulk the overlap seam of any exposed pipe sections that are located above the roof line. Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 39: Horizontal Termination Requirements

    Figure 7.15 Figure 7.15 Important Notice: Heat shields may not be fi eld constructed. Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 40 DVP-TRAP2 can adjust 4 in. (5-3/8 to 9-3/8) DVP-HPC1 can adjust 2-1/8 in. (4-1/4 to 6-3/8) DVP-HPC2 can adjust 4-1/8 in. (6-3/8 to 10-1/2) Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 41: Electrical Information

    Copper ground attached GRN wire to GRN screw with inside box GRN wire Figure 8.1 Junction Box Detail Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 42 GROUND TO FIREPLACE PLUG IN CHASSIS WIRES BATTERY PACK (TO BROWN) REMOTE PLUG IN VALVE Figure 8.3 Intellifi re Ignition Wiring Diagram with Remote Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 43 Figure 8.4 Junction Box Wired to Wall Switch or BC10 (1/4 in. male) as shown. Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 44: Gas Information

    • If substituting for these components, please consult local codes for compliance. Check with your local gas utility to determine proper orifi ce size. Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 45: Air Shutter Setting

    NOTICE: If sooting occurs, provide more air by opening the air shutter. Air Shutter Settings Models DV3732 3/16 in. 1/2 in. DV4236 1/4 in. Full Open Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 46: Finishing

    3-1/2 IN. 0 IN. 0 IN. HIGH TEMPERATURE SEALANT (300° F/149° C MIN.) SEAL JOINT = NON-COMBUSTIBLE ZONE Figure 10.2 Non-combustible Facing Diagram - DV4236 Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 47: Mantel And Wall Projections

    See Dimension B on Appliance Dimension Diagram (Figure 3.1 DV3732) (Figure 3.2 DV4236) Figure 10.5 Non-Combustible Mantel Leg or Wall Projections (Acceptable on both sides of opening) Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 48: Decorative Front Dimensions For Finishing

    4 IN. MAXIMUM THICKNESS Stop fi nishing material fl ush with fi replace surround opening. Figure 10.7 Inside Fit NON-COMBUSTIBLE ZONE Figure 10.6 Non-Combustible Zone Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 49: Elevated Hearth Systems

    Note 1. Add dimensions to Wall Penetration (Figure 5.2) and Rough Opening Height (Figure 3.5). Note 2. Verify Marble Cut Lengths on site prior to cutting. Note 3. Dimensions assume use of a 3/4 in. Hearth Pad. Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 50: Appliance Setup

    LATCHES (BOTH BOTTOM AND TOP) GLASS ASSEMBLY Figure 11.1 Fixed Glass Assembly Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 51: Install The Log Assembly

    Log #3 SRV2355-703 (LOGS-3732 and LOGS-DV4236): Locate the bottom hole on Log #3 with the shoulder screw on the right front side of the base pan. See Figure 5. Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 52 Log #6 SRV2391-711 (LOGS-DV4236): Place the right end of Log #6 on the base pan and the left end onto Logs #1 and #3, so that one limb is touching each log as shown in Figure 8. 2355-910E Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 53: Ember And Lava Rock Placement

    3 to 5 applications. Delayed ignition may occur. LAVA ROCK NO EMBERS IN SHADED AREA Figure 11.4 Figure 11.2 Placement of Embers EMBERS Figure 11.3 Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 54: Install Decorative Front/Hood

    4. Install hood on appliance by inserting into the two hood clips. See Figure 11.5. SHIPPING HOOKS (Hook location varies by model) Figure 11.5 Install Decorative Front and Hood Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 55: Reference Materials

    5 in. 12 in. (127 mm) (305 mm) 6 in. (152 mm) DVP-HVS (Vent Support) DVP-WS (Wall Shield Firestop) Figure 12.1 DVP Vent Components Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 56 DVP-TRAP 5-3/8 in. 9-3/8 in. Trap2 Horizontal Termination Cap 137 mm 238 mm DVP-TRAP2 DVP-TRAP1 DVP-TRAPK2 DVP-TRAPK1 DVP-HPC2 DVP-HPC1 Figure 12.2 DVP Vent Components Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 57 (352 mm) (241 mm) 26 in. 660 mm 14 in. (356 mm) DVP-HSM-B DRC-RADIUS Extended Heat Shield Cap Shield Figure 12.3 DVP Vent Components Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 58 3/8 in. (10 mm) 1 in. (25 mm) 7-3/4 to 10-3/8 in. (197 to 264 mm) DVP-FBHT FireBrickTermination Cap Figure 12.4 DVP Vent Components Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 59 (330 mm) 15 in. (381 mm) SLP-HRC-SS Horizontal Termination Cap DVP-TB1 DVP-TB1 SL-2DVP SLP90 ASSEMBLY DVP-TB1 Figure 12.6 SLP Vent Components HORIZONTAL TERMINATION CAP Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 60 12 in. 5-1/2 in. 220 mm 38 mm 305 mm 146 mm SLP-WS SLP-FS Wall Shield Firestop Ceiling Firestop Figure 12.7 SLP Series Vent Components Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 61 26 in. 660 mm 2-5/16 in. 14-7/16 in. 59 mm 367 mm DVP-HSM-B SLP-WT-BK Extended Heat Shield Wall Thimble-Black Figure 12.8 SLP Series Vent Components Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 62 343 mm 7-3/4 to 10-3/8 in. (197 to 264 mm) DVP-FBHT SLK-SNKD Horizontal Snorkel Termination Cap Termination Cap Figure 12.9 SLP Series Vent Components Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 63 COAXIAL to COLINEAR VENTING LINK-DV30B DVP-2SL DV-46DVA-GCL Flex Liner Kit Adapter Coaxial/Colinear Appliance Connector Figure 12.10 Coaxial to Colinear Vent Components Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
  • Page 64: Accessories

    Please contact your Hearth & Home Technologies dealer with any questions or concerns. For the location of your nearest Hearth & Home Technologies dealer, please visit www.hearthnhome.com. Printed in U.S.A. - Copyright 2016 Hearth & Home Technologies • DV3732, DV3732L, DV4236 Installation Manual • 2355-980 Rev. H • 3/16...
