Hearth and Home Technologies Simplifyre SFE-35 Homeowner's Installation & Operating Manual

Builder box
Hide thumbs Also See for Simplifyre SFE-35:
Table of Contents

Advertisement

Quick Links

See also: Homeowner's Installation and Operating Manual
Model: SFE-35
INSTALLER/CONSUMER SAFETY
INFORMATION
PLEASE READ THIS MANUAL BEFORE
INSTALLING AND USING APPLIANCE.
WARNING!
IF THE INFORMATION IN THIS
MANUAL IS NOT FOLLOWED
EXACTLY, AN ELECTRICAL SHOCK
OR FIRE MAY RESULT, CAUSING
PROPERTY DAMAGE, PERSONAL
INJURY OR LOSS OF LIFE.

FOR YOUR SAFETY

SERVICE MUST BE PERFORMED BY
A QUALIFIED SERVICE AGENCY.
DO NOT STORE OR USE GASOLINE
OR OTHER FLAMMABLE VAPORS
AND LIQUIDS IN THE VICINITY OF
THIS OR ANY OTHER APPLIANCE.
ANSI / UL 2021. Fixed or location dedicated electric room heater.
Installer: do not discard this manual -- leave for home owner
1
US
C
Hearth & Home Technologies Inc. • SFE-35 • 4050-313 Rev C • 01/08
BUILDER BOX
TUV Listed as SFE-35
Homeowner's Installation & Operating Manual
Note: The device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including
interference that may cause undesired operation.

Advertisement

Table of Contents
loading

Related Manuals for Hearth and Home Technologies Simplifyre SFE-35

Summary of Contents for Hearth and Home Technologies Simplifyre SFE-35

  • Page 1: For Your Safety

    ANSI / UL 2021. Fixed or location dedicated electric room heater. Installer: do not discard this manual -- leave for home owner Hearth & Home Technologies Inc. • SFE-35 • 4050-313 Rev C • 01/08 TUV Listed as SFE-35 Homeowner’s Installation & Operating Manual Note: The device complies with Part 15 of the FCC Rules.

  • Page 2: Table Of Contents

    Please read the installation & operation instructions before using this appliance. 1 Important Instructions Hearth & Home Technologies Inc. • SFE-35 • 4050-313 Rev C • 01/08 Congratulations! The information contained in this owner’s manual unless noted otherwise, applies to all models.

  • Page 3: Important Instructions

    fi re, or damage the heater. Hearth & Home Technologies Inc. • SFE-35 • 4050-313 Rev C • 01/08 WARNING! Improper installation, adjustment, altera- tion, service or maintenance can cause injury or prop- erty damage.

  • Page 4: A Unpacking The Unit

    Total Watts ..... . . 1050 Watts Heater Rating ... . .1000 Watts/3415 BTU Hearth & Home Technologies Inc. • SFE-35 • 4050-313 Rev C • 01/08 F. Hardwire Electrical Connections...

  • Page 5: Fireplace Dimensions

    85.7 cm 1/2 in. (13 mm) 48 in. 121.9 cm Figure 2.1 Fireplace Specifi cations and Framing Dimensions Hearth & Home Technologies Inc. • SFE-35 • 4050-313 Rev C • 01/08 33.6 in. 85.4 cm 30.5 in. 77.5 cm Note: Nailing flanges may be...

  • Page 6: Operating Instructions

    Learn Button FLAMES HEATER Hearth & Home Technologies Inc. • SFE-35 • 4050-313 Rev C • 01/08 B. Remote Control Initialization This procedure is required only when the unit is installed or the transmitter is replaced and is not affected by the loss of power.

  • Page 7: Electrical Wiring

    • Unplug the bulb from the socket. • Replace the bulb. • Re-assemble in the reverse order. Hearth & Home Technologies Inc. • SFE-35 • 4050-313 Rev C • 01/08 Interlock on Media Cabinet only 12 VOC Power Supply Ember Bed & Back Log B.
  • Page 8 Thermostat turns heater/fan ON/OFF as room temperature requires it • Switch 1 between terminal 1 and 2 • Switch 2 between terminal 1 and 3 • Thermostat between terminal 4 and 5 Hearth & Home Technologies Inc. • SFE-35 • 4050-313 Rev C • 01/08...

  • Page 9: Replacement Parts List

    Left Refractory Right Rear Refractory Left Rear Refractory Sheet Rock Ledge Back Refractory Hardwire Power Cord (SFE-35 only) Hearth & Home Technologies Inc. • SFE-35 • 4050-313 Rev C • 01/08 SN # Cutoff Stocked at Depot PART NUMBER 4050-176...

  • Page 10: Warranty

    ADDITIONAL INFORMATION. If you would like information on current HHT products or want to locate a dealer in your area, call 1-800-927-6841 ©2003 Heatilator® is a Registered Trademark of Hearth & Home Technologies Inc Hearth & Home Technologies Inc. • SFE-35 • 4050-313 Rev C • 01/08...
