SFE-CDLB3530PP CORTLAND Plug & Play
SFE-MKLB3530PP MACKINTOSH Plug & Play
INSTALLER/CONSUMER SAFETY
INFORMATION
PLEASE READ THIS MANUAL BEFORE
INSTALLING AND USING APPLIANCE.
WARNING!
IF THE INFORMATION IN THIS
MANUAL IS NOT FOLLOWED
EXACTLY, AN ELECTRICAL SHOCK
OR FIRE MAY RESULT, CAUSING
PROPERTY DAMAGE, PERSONAL
INJURY OR LOSS OF LIFE.
FOR YOUR SAFETY
SERVICE MUST BE PERFORMED BY
A QUALIFIED SERVICE AGENCY.
DO NOT STORE OR USE GASOLINE
OR OTHER FLAMMABLE VAPORS
AND LIQUIDS IN THE VICINITY OF
THIS OR ANY OTHER APPLIANCE.
C
ANSI / UL 2021. Fixed or location dedicated electric room heater.
Installer: do not discard this manual -- leave for home owner
1
Hearth & Home Technologies Inc. • Plug & Play • 4050-317 Rev A • 04/08
Homeowner's Installation & Operating Manual
Note: The device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including
interference that may cause undesired operation.
US
TUV Listed as Model SFE-35C
Advertisement
Table of Contents
Related Manuals for Hearth and Home Technologies SFE-CDLB3530PP
Summary of Contents for Hearth and Home Technologies SFE-CDLB3530PP
-
Page 1: For Your Safety
Model: SFE-CDLB3530PP CORTLAND Plug & Play SFE-MKLB3530PP MACKINTOSH Plug & Play INSTALLER/CONSUMER SAFETY INFORMATION PLEASE READ THIS MANUAL BEFORE INSTALLING AND USING APPLIANCE. WARNING! IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED EXACTLY, AN ELECTRICAL SHOCK OR FIRE MAY RESULT, CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. -
Page 2: Table Of Contents
Congratulations! Congratulations on selecting a Simplifyre electric fi replace. The information contained in this owner’s manual unless The unit you have selected is designed to provide the noted otherwise, applies to all models. utmost in safety, reliability and effi ciency. Your new Simplifyre electric fi... -
Page 3: Important Instructions
Important Instructions WARNING! Risk of Fire! WARNING! Improper installation, adjustment, altera- tion, service or maintenance can cause injury or prop- DO NOT: erty damage. Refer to the owner’s information manual • install or operate damaged heater provided with this heater. For assistance or additional •... -
Page 4: Unpacking The Unit
A. Unpacking the Unit WARNING! Do NOT use this appliance if any part has been under water. Immediately call a qualifi ed service techni- cian to inspect and to replace any part of the electrical system if necessary. Carefully remove packaging from the unit. The front screen is held in place with four Phillips head screws. To remove the screen, extract the screws. -
Page 5: Fireplace Dimensions
Fireplace Dimensions 39" 5" 39" 12" Alcove finished dimensions 39" H x 39" W x 12" D Figure 2.1 Framing Dimensions Hearth & Home Technologies Inc. • Plug & Play • 4050-317 Rev A • 04/08... -
Page 6: Operating Instructions
OPERATING INSTRUCTIONS Ensure the appliance is connected to a properly grounded electrical outlet on a minimum 15 AMP circuit. If a new outlet is required, it should be installed by a qualifi ed electrician according to applicable building codes. A. Remote Control Note: If the fi... -
Page 7: Electrical Wiring
Electrical Wiring Interlock on Lamp Media Cabinet only Projector Remote Receiver Motor Flame Power Supply Module Heat Flame 4050-309 Terminal Strip Wall Switch Heat Hot Line NEMA-5 IEC 320 C13/C14 12 VOC Ground Power Supply Neutral Branch Circuit Ember Bed & Back Log 4050-310 Wall Thermostat LED LED LED... - Page 8 E. Optional Wall Switch / Thermostat Wiring Connections instructions The optional wall switch and thermostat wiring is low voltage and must be separated from power wiring. Do not connect the switches or thermostat to house power. To control the fi replace with a single switch: (fl...
-
Page 9: Warranty
Warranty Warranty Hearth & Home Technologies Inc. (HHT) Electric Fireplaces are tested and inspected prior to shipment and are guaranteed from defect to the purchaser of each new product. Any part which proves to be defective in material or workmanship under normal use within one year will be repaired or replaced without charge.* The Company will not be responsible for any expense incurred for installation, removal from service, or transportation costs.
