- Page 1 TITAN ™ Charger / Power Supply OWNER’S MANUAL...
-
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ..................1 FEATURES ....................1 SAFEGUARDS ....................2 GROUNDING/EARTHING ................2 Charging ......................3 Applications ..................... 3 Three Stage Charging Methodology ............... 4 LED Indications....................5 OPERATION AS DC CAMERA SUPPLY FROM MAINS ....... 6 FCC NOTICE .................... -
Page 4: Introduction
Three Stage Charging modes. When the Titan T2 is being used as a power supply, the battery (right side only) functions as an automatic backup, just in case AC power is lost. -
Page 5: Safeguards
SAFEGUARDS Power Sources: This unit was designed to operate at mains voltages from 90 to 250 Volts AC, 50-60 Hz. Risk of Electrical Shock: Refer servicing to qualified service personnel. TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. -
Page 6: Charging
Charging As with all Anton/Bauer chargers, charging with TITAN T2 is fully automatic. Mount any Digital Logic Series or Logic Series battery to the TITAN T2 and it will automatically determine the appropriate charge routine and execute it. Applications The Titan T2 will charge any Anton/Bauer Logic Series Gold Mount battery including model: ProPac 13/14, Trimpac 13/14, Digital ProPac 13/14, Digital Trimpac 13/14, HyTRON, Dionic 80 or ProFormer battery. -
Page 7: Three Stage Charging Methodology
Three Stage Charging Methodology In general, the TITAN T2 will deliver a three stage charge routine to each battery. 1. Stage One will deliver a high rate charge matched to the capabilities of the battery (typically a one or two hour rate, depending on battery type). During this... -
Page 8: Led Indications
100% charged. LED Indications The TITAN T2 has two sets of three LEDs (one red, two green). The green status LED indicates: Steady green – line voltage is present with no power drawn through camera output; Flashing green - line voltage is present, powering camera; Off – line voltage not present, camera powered by battery, if there is a battery presently mounted on Titan T2. -
Page 9: Operation As Dc Camera Supply From Mains
5 minutes, the battery will be re-evaluated prior to continuing charge. If AC line voltage is removed from the TITAN T2, and a charged battery is mounted on the right side of the unit, power from the battery will be routed to the camera. If AC line... -
Page 10: Fcc Notice
70 watts at 16.4 volts Fuse Rating 5 amp (PCB Mounted) *IN CAMERA POWER MODE AT 4 PIN XLR CONNECTOR. FUSE/TYPE REPLACEMENT The fuse of the TITAN T2 is a PCB mounted device which should only be replaced by a qualified service technician. -
Page 11: Warranty
Support Group to establish this warranty. Proper registration will also enable us to provide update information on the battery system. All new Anton/Bauer products have been thoroughly tested and inspected prior to shipment. This product is warranted against defect in materials and workmanship for a period of one (1) year from date of purchase. - Page 12 The worldwide standard ® The following are registered trademarks of Anton/Bauer, Inc.: ACS, Anton/Bauer, Anton/Bauer Logo, Automatique, ComPac, Dionic, Gold Mount, HyTRON, Impac, InterActive, InterActive 2000 Logo, LifeSaver, Logic Series, Logic Series Logo, PowerStrap, ProPac, SSP, Satellight, Snap On, The worldwide standard, TITAN, Triconn, TrimPac, Ultralight, Ultrakit Anton/Bauer, Inc.
