PowerCharger
DUAL 2722
Charger / Power Supply
OWNER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Interactive 2000 PowerCharger and is the answer not in the manual?

Questions and answers

Related Manuals for Anton/Bauer Interactive 2000 PowerCharger

Summary of Contents for Anton/Bauer Interactive 2000 PowerCharger

  • Page 1 PowerCharger DUAL 2722 Charger / Power Supply OWNER’S MANUAL...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS INTRODUCTION…………………………………………………………………...1 FEATURES…………………………………………………………………………..1 SAFEGUARDS………………………………………………………………………2 GROUNDING/EARTHING………………………………………………………...2 OPERATION…………………………………………………………………………3 Charging... 3 Applications ... 3 Three Stage Charging Methodology ... 4 LED Indications ... 5 LCD Indications ... 6 DDM (DIAGNOSTIC/DISCHARGE MODULE)... 7 To Operate The DDM... 8 “AUTOCAL” Feature ... 9 OPERATION AS DC CAMERA SUPPLY FROM MAINS ...

  • Page 4: Introduction

    INTRODUCTION The DUAL 2722 is a simultaneous 2 position Interactive 2000 PowerCharger fast charger with 70 watt DC camera power supply. Series circuits that are employed in every Anton/Bauer charger. The InterActive charge programming provides all charge termination and protection routines for safe, reliable, chemistry independent charging.

  • Page 5: Safeguards

    SAFEGUARDS Power Sources: This unit was designed to operate at mains voltages from 90 to 264 Volts AC, 50-60 Hz. Risk of Electrical Shock: Refer servicing to qualified service personnel. TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE.

  • Page 6: Operation

    Charging As with all Anton/Bauer chargers, charging with DUAL 2722 is fully automatic. Mount any Digital Logic Series or Logic Series battery to the DUAL 2722 and it will automatically determine the appropriate charge routine and execute it. Applications The DUAL 2722 will charge any Anton/Bauer Logic Series Gold Mount battery including model: ProPac 13/14, Trimpac 13/14, Digital ProPac 13/14, Digital Trimpac 13/14, HyTRON, Dionic or ProFormer battery.

  • Page 7: Three Stage Charging Methodology

    Three Stage Charging Methodology In general, the DUAL 2722 will deliver a three stage charge routine to each battery. 1. Stage One will deliver a high rate charge matched to the capabilities of the battery (typically a one or two hour rate, depending on battery type). During this...

  • Page 8: Led Indications

    LED Indications The DUAL 2722 has two sets of two LEDs (one red, one green) and one green status LED in the center. The green status LED indicates: Steady green – line voltage is present; Off – line voltage not present..

  • Page 9: Lcd Indications

    1- - - - - - - 2 – WAIT CAMERA MODE The Signature Display can be viewed by pressing DUAL 2722 Rev. #3.xx and holding the TEST button from the Main Display on the PowerCharger to obtain model Discharger NOT INSTALLED information, Software revision number and installation of DDM (discharger).

  • Page 10: Ddm (Diagnostic/Discharge Module)

    DDM (DIAGNOSTIC/DISCHARGE MODULE) A standard feature with the DUAL 2722, the DDM completes a battery management system, capable of testing battery capacity and identifying battery anomalies before they appear in the field. The DDM will perform a standard or a 24 hour test. The standard test is a full...

  • Page 11: To Operate The Ddm

    To Operate The DDM 1. Mount the battery to any position on the PowerCharger. When the PowerCharger has completed its communication with the battery, the ALTERNATING RED and GREEN LEDs will stop and the battery will begin its charge routine. The battery information and position number will appear on the LCD display.

  • Page 12: Autocal" Feature

    “AUTOCAL” Feature When a DDM is installed in the PowerCharger, a special InterActive mode is automatically enabled for DIGITAL batteries placed on the PowerCharger at any time. The PowerCharger will interrogate the status of the DIGITAL battery to determine whether the battery has received a “learning” cycle or “calibrate” cycle within certain parameters.

  • Page 13: Operation As Dc Camera Supply From Mains

    “CAMERA” position. The DUAL 2722 will remember the point at which it left its charge routine for the battery positioned on the right side of the charger. The left side of the charger will continue as a dedicated charging position, regardless of the selected function of the right side of the DUAL 2722.

  • Page 14: Fcc Notice

    70 watts at 16 volts Fuse Rating 5 amp (PCB Mounted) *IN CAMERA POWER MODE AT 4 PIN XLR CONNECTOR. FUSE/TYPE REPLACEMENT The fuse of the DUAL 2722 is a PCB mounted device which should only be replaced by a qualified service technician.

  • Page 15: Warranty

    Support Group to establish this warranty. Proper registration will also enable us to provide update information on the battery system. All new Anton/Bauer products have been thoroughly tested and inspected prior to shipment. This product is warranted against defect in materials and workmanship for a period of one (1) year from date of purchase.
