- Page 1 TITAN™ 70 Charger / Power Supply OWNER’S MANUAL...
-
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ..................1 FEATURES ....................1 SAFEGUARDS ....................2 GROUNDING/EARTHING ................2 Charging ......................3 Applications ..................... 3 Three Stage Charging Methodology ............... 4 LED Indications....................5 OPERATION AS DC CAMERA SUPPLY FROM MAINS ....... 6 POWER LOSS .................... -
Page 4: Introduction
INTRODUCTION The TITAN 70 is the smallest and lightest package available in both a charger and power supply. It incorporates all of the Logic Series circuits that are employed in every Anton/Bauer charger. The fast charge feature makes it an ideal complement to a current Anton/Bauer battery system and given its small size is ideal for travel. -
Page 5: Safeguards
SAFEGUARDS Power Sources: This unit was designed to operate at mains voltages from 90 to 250 Volts AC, 50-60 Hz. Risk of Electrical Shock: Refer servicing to qualified service personnel. TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS UNIT TO RAIN OR MOISTURE. -
Page 6: Charging
Charging As with all Anton/Bauer chargers, charging with TITAN 70 is fully automatic. Mount any Logic Series battery to the TITAN 70 and it will automatically determine the appropriate charge routine and execute it. Applications The Titan 70 will charge any Anton/Bauer Logic Series Gold Mount battery including model: ProPac 13/14, Trimpac 13/14, Digital ProPac 13/14, Digital Trimpac 13/14, HyTRON, or ProFormer battery. -
Page 7: Three Stage Charging Methodology
Three Stage Charging Methodology In general, the TITAN 70 will deliver a three stage charge routine to each battery. 1. Stage One will deliver a high rate charge matched to the capabilities of the battery (typically a one or two hour rate, depending on battery type). During this... -
Page 8: Led Indications
LED Indications The TITAN 70 has three LEDs (one red, two green). One green LED indicates AC line voltage status. If the green status LED is steady, then line voltage is present. If the green status LED is flashing, then AC Line voltage has been removed. -
Page 9: Operation As Dc Camera Supply From Mains
TITAN 70 will again resume battery charging. If AC line voltage is removed from the TITAN 70, and a charged battery is mounted on the unit, power from the battery will be routed to the camera. When AC line voltage is restored, the battery will be re-evaluated for a proper charge routine. -
Page 10: Fcc Notice
Output Voltage 16.4 VDC Fuse Rating 7 amp Surface Mount Maximum Power 70 watts at 16.4 volts FUSE/TYPE REPLACEMENT The fuse of the TITAN 70 is a PCB mounted device which should only be replaced by a qualified service technician. -
Page 11: Warranty
DEPARTMENT to establish this warranty. Proper registration will also enable us to provide update information on the battery system. All new Anton/Bauer products have been thoroughly tested and inspected prior to shipment. This product is warranted against defect in materials and workmanship for a period of one (1) year from date of purchase. - Page 12 5,057,383 Other patents, U.S. and International may apply or are pending. The worldwide standard The following are registered trademarks of Anton/Bauer, Inc.: ACS, Anton/Bauer, Anton/Bauer Logo, Automatique, ComPac, Gold Mount, HyTRON, Impac, InterActive, InterActive 2000 Logo, LifeSaver, Logic Series, Logic Series Logo, PowerStrap, ProPac, SSP, Satellight, Snap On, The worldwide standard, TITAN, Triconn, TrimPac, Ultralight, Ultrakit Anton/Bauer, Inc.
