Anton/Bauer ProPac 13/14 Owner's Manual

Logic series battery system
Hide thumbs Also See for ProPac 13/14:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Owner's Manual, Operating Instructions
®
®
BATTERY SYSTEM
®
ProPac
13/14
®
Trimpac
13/14
OWNER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ProPac 13/14 and is the answer not in the manual?

Questions and answers

Related Manuals for Anton/Bauer ProPac 13/14

Summary of Contents for Anton/Bauer ProPac 13/14

  • Page 1 ® ® BATTERY SYSTEM ® ProPac 13/14 ® Trimpac 13/14 OWNER’S MANUAL...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS FEATURES ... 1 HIGH VOLTAGE DESIGN ... 1 APPLICATIONS ... 2 ® PROPAC ... 2 ® TRIMPAC ... 3 CHARGING WITH LOGIC SERIES “OVER-DISCHARGED” BATTERIES ... 4 PREVENTATIVE MAINTENANCE ... 5 GUIDELINES FOR OPTIMUM PERFORMANCE AND MAXIMUM LIFE... 6 SHORT / FUSE REPLACEMENT...

  • Page 3: Features

    The Logic Series connector assembly features multiple gold plated, self aligning contacts and is compatible with all existing Anton/Bauer camera mounts and accessories. 5. Individual Computer Testing - Like all professional Anton/Bauer batteries, the Logic Series battery has been individually computer tested.

  • Page 4: Applications

    NiCad batteries. The 14.4 volt Logic Series battery could damage such equipment. Check with the equipment manufacturer or the Anton/Bauer Service Center prior to using a 14.4 volt battery. If a question of applicability exists, the 13.2 volt Logic Series battery is fully compatible with any equipment specifying a “12 volt DC source”.

  • Page 5: Trimpac

    The lightweight high energy Trimpac battery is the ideal match for the latest generation of smaller CCD cameras and camcorders. The Trimpac will provide excellent run times in applications previously using slide-in type batteries. Run time improvements to 100% are quite common with the Trimpac.

  • Page 6: Over-Discharged" Batteries

    A battery that has been inadvertently allowed to become “over-discharged” will automatically trigger a special rejuvenation routine contained in all Anton/Bauer Logic Series Chargers. In such cases the red/green alternating LED’s, on the charger, indicate that the automatic rejuvenation cycle is bringing the battery back up to a safe charging voltage.

  • Page 7: Preventative Maintenance

    PREVENTATIVE MAINTENANCE The Logic Series battery incorporates unique battery management features. Together with Anton/Bauer diagnostic accessories, an effective preventative maintenance program can easily be created to optimize the return on battery investment and greatly simplify battery management operations. ® The PowerCharger , coupled with a DDM (Diagnostic Discharge Module), will provide a complete battery management system.

  • Page 8: Guidelines For Optimum Performance And Maximum Life

    2. Use only Anton/Bauer Logic Series Lifesaver Chargers and keep batteries on the charger until just prior to being used. 3. Return batteries to the Logic Series Charger as soon as possible after use, preferably within 24 hours.

  • Page 9: Short / Fuse Replacement

    Anton/Bauer publishes a comprehensive “Video Battery Handbook” to help you further maximize the life and performance of your new battery. This guide is available, at no charge, by contacting Anton/Bauer at 1- 800-422-3473 or 203-925-4991 or fax 203-929-9935. SHORT / FUSE REPLACEMENT...

  • Page 10: Charge Status Indicator

    If the battery continues to blow fuses, test the equipment being powered for any short circuit at the D.C. power input. If no short is found, contact the Anton/Bauer Customer Support Department for assistance at 1-800-541-1667 or 203-925-4991 or fax 203- 929-9935.

  • Page 11: Service

    In the unlikely event a Logic Series battery fails to deliver acceptable performance it must be returned to the Anton/Bauer Service Center that is the only facility qualified and equipped to service the Logic Series batteries and calibrate the electronic components and sensors.

  • Page 12: Specifications

    Proper registration will also enable us to send you important update information. This new Anton/Bauer Logic Series battery has been 100% tested prior to shipment and is warranted against defects in materials and workmanship for a period of three years from date of purchase when this battery is used in conjunction with Anton/Bauer Logic Series Lifesaver Chargers.
  • Page 13 *Performance is warranted at a minimum of 70% of rated capacity. If you have any questions regarding applications or specifications, or to obtain warranty service on this or any Anton/Bauer product, contact the Anton/Bauer Customer Support Department. See back page for contact information.
  • Page 14 Please call 1-800-8-BATTERY™ for information on Ni-Cd battery recycling and disposal bans/restrictions in your area. Anton/Bauer’s involvement in this program is part of our commitment to preserving our environment and conserving our natural resources. For recycling information outside the United States and Canada, contact Anton/Bauer.
