WARNING: Do not operate appliance with
the glass front removed, cracked or
broken.
•
The use of substitute glass will void all product
warranties.
•
Care must be taken to avoid breakage of the glass.
•
Do not operate this fireplace without the glass front
or with a broken glass front.
•
Replacement of the glass should be done by a
licensed or qualified service person.
•
Do not remove the glass door when unit is hot
to the touch.
•
NOTE: Inspect the door gasket. The braided door
seal gasket has a small overlap area hear the
middle of the top black extrusion. Identify this area
and install the door with this area at the top.

Glass Door Removal Procedure

1. Remove upper and lower louvre assemblies and set
aside. Refer to louvre installation instructions.
2. Using gloves, carefully unlatch the latches (3) along
the bottom edge of the glass door. Then as the top
latches are unlatched, continue to place gentle
pressure to the glass door to reduce the chances of
the door being dropped accidentally.
3. Once all latches have been secured, pull the door
(4) outward from the face of the fire chamber.
4. Take care during handling and cleaning of the glass
door so that it is not dropped or accidentally broken.
5. Cleaning of the glass should only be done when the
glass door is cool. Refer to Glass Cleaning section.
6. To reinstall glass door, carefully center the door
onto the face of the fireplace (left to right), second,
shift the door assembly upwards slightly, then
secure door with the throw-over latches above and
below the firechamber. By shifting the door upwards
before latching, the upper door latches will be less
visible once the upper louvre is installed.
7. Reinstall the upper and lower louvre assemblies.
Refer to louvre installation.

Glass Cleaning

It will be necessary to clean the glass periodically.
During start-up, condensation - which is normal - forms
on the inside of the glass and causes dust, lint, etc. to
cling to the glass surface. Also, initial paint curing can
deposit a slight film on the glass. In some geographic
areas, a white film may be deposited on the glass due
to combustion of some of the constituents of natural
gas. It is therefore recommended that initially the glass
77531

Operating Instructions

be cleaned two or three times with non-abrasive
common household cleansers and warm water. After
that, the glass should be cleaned two or three times a
season depending on the amount that the fireplace is
used.
To remove, simply unlatch the top and bottom door
latches and carefully pull door forward. Use of gloves
recommended.
The fireplace is shipped without the louvre assemblies
installed. Various styles and finishes are available as
options. Contact your nearest Temco dealer/distributor
for information on the Grill Kits available.
1. To install the upper louvre assembly, the second
2. Once the second louvre blade has engaged the top
After completing Steps 1 and 2, the louvre assembly
should look like the illustration shown in Figure 31.
Fig. 30 Hook first or second louvre blade (depending on
fireplace model) onto top tabs of louvre brackets.
Temco DV5200, DV6400 Series
Do not clean when the glass is hot.
Do not strike or abuse glass.
Do not place glass door on edge after
removal.

Louvre Installation

louvre blade from the top on each louvre assembly
will hook onto the top tabs of the louvre brackets.
(Fig. 30)
tab of the end brackets, swing the bottom of the
louvre assembly inward so the louvre hangs flush
with the fireplace face. (Fig. 30)
