PLEASE READ THIS MANUAL
BEFORE INSTALLING AND
USING HEATERS
IMPORTANT: Read all instruc-
tions and warnings carefully
before starting installation. Fail-
ure to follow these instructions
may result in a possible fire haz-
ard and will void the warranty.
WARNING: If the information in
this manual is not followed ex-
actly, a fire or explosion may
result causing property damage,
personal injury or loss of life.
— Do not store or use gasoline or
other flammable vapors and
liquids in the vicinity of this or
any other appliance.
— What to Do If You Smell Gas
•
Do not try to light any appli-
ance.
•
Do not touch any electrical
switch; do not use any phone
in your building.
•
Immediately call your gas
supplier from a neighbor's
phone. Follow the gas
supplier's instructions.
•
If you cannot reach your gas
supplier, call the fire depart-
ment.
— Installation and service must be
performed by a qualified in-
staller, service agency or the
gas supplier.
This is an unvented gas-fired
heater. It uses air (oxygen) from
the room in which it is installed.
Provisions for adequate combus-
tion and ventilation air must be
provided. Refer to Page 4.
Models with "N" after the model number use natural gas;
models with "P" after the model number use Propane
(LP) gas.
INSTALLER: DO NOT DISCARD THIS MANUAL - Leave in fireplace for homeowner.
Vent-Free Gas Fireplaces
Models:
VF36RN, VF36RNH, VF36RP
Homeowner's Installation and
Operating Instructions
This appliance is UL Certified under ANSI Standard
Z21.11.2-2000 as an unvented room heater
Temco Fireplace Products
410 Admiral Blvd. • Mississauga, Ontario, Canada L5T 2N6 • 905-670-7777
Gas Fired
Unvented
Room Heaters
5L24
78586 11/03 Rev. 8
Advertisement
Table of Contents
Related Manuals for Temco VF36RN
Summary of Contents for Temco VF36RN
-
Page 1: Operating Instructions
WARNING: If the information in Models: this manual is not followed ex- VF36RN, VF36RNH, VF36RP actly, a fire or explosion may result causing property damage, personal injury or loss of life. — Do not store or use gasoline or... -
Page 2: Table Of Contents
This book contains your operating and installation instructions and should be kept in a safe place. For you to realize all the advantages and use of the reliable service that has been engineered into your TEMCO fireplace, you must carefully follow all of the instructions contained in this book regarding installation and operation of the fireplace. -
Page 3: Important Information
Temco VF36RN/RNH/RP Important Information • Use only with two-stage regulator. INSTALLER: Please leave these instructions with the • DO NOT use this heater if any part of it has been under owner. water. Immediately call a qualified technician to inspect the... -
Page 4: Provision For Adequate Combustion And Ventilation Air
Temco VF36RN/RNH/RP If additional ventilation from adjoining room(s) is WARNING: Do not allow fans to blow directly into the supplied with grilles or doorless openings, add the fireplace. Avoid any drafts that alter burner flame volume of these rooms to compute the total volume pattern. - Page 5 Temco VF36RN/RNH/RP Ventilation air from outdoors for unusually tight open to the outdoors. These spaces include attics and construction. crawl spaces. Follow the National Fuel Gas Code WARNING: If the area in which the heater may be NFPA 54/ANSI Z223.1, Section 5.3, Air for Combustion...
-
Page 6: Fireplace Dimensions
Temco VF36RN/RNH/RP Fireplace Dimensions Rough Opening 21¹⁄₈" Depth 35³⁄₈" 1/2" 14¹⁄₂" Rough Opening Width 36" 1/2” Clearance to Combustibles not Required at This Point Rough Opening Height 1/2" Gas Connection 32¹⁄₈" Left Side Only 33¹⁄₂" 17" 31¹⁄₈" 3⁷⁄₈" 6⁷⁄₈" 36"... -
Page 7: Installation & Operating Instructions
Temco VF36RN/RNH/RP Installation & Operating Instructions Locating the Fireplace Fan Kit - Optional Figure 3 shows some of the many ways your fireplace (Part #BL-3) may be installed. Consider the traffic pattern in your For installation of the optional fan, please refer to the room and the location of doors and windows. -
Page 8: Clearances
Temco VF36RN/RNH/RP of 20¹⁄₄” above the fireplace opening. Required When the fireplace is installed over carpeting, vinyl tile clearance varies with the amount of projection. or any combustible material other than wood flooring, it (Fig. 6a) must be installed on a metal or wood panel extending The mantel profile must fall within the cross- its full width and depth. -
Page 9: Installation
Temco VF36RN/RNH/RP Step 2: Install the Firebox Install the firebox into the framed opening by setting it 10" directly in front of the opening and sliding it into the proper position. 8" Heat Resistant Step 3: Level the Firebox 22"... -
Page 10: Gas Connection
Temco VF36RN/RNH/RP Gas Connection WARNING Gas Specifications DANGER OF PROPERTY DAMAGE, BODILY INJURY OR DEATH. BTU/Hr Never use a match or open flame to test for Model Fuel leaks. Never exceed specified pressures for VF36RN Natural 29,000 18,000 testing. High pressures may damage the appli-... -
Page 11: Gas Pressure Check
Temco VF36RN/RNH/RP When installing this fireplace at an elevation above valve. The pressure connections accept 1/4” I.D. hose 2,000 feet, it may be necessary to decrease the input or tubing. rating by changing the existing burner orifice to a The pressure should be checked with the appliance smaller size. -
Page 12: Log Installation
Fig. 10 Correct log placement. WARNING: Do not use more embers than those supplied with your unit. Do not use embers other than genuine “Platinum Embers” supplied by Temco Fire- place Products, Part No. 78037. When you have completed these steps, compare log positions with Figure 10. - Page 13 Temco VF36RN/RNH/RP Installation of Optional Wireless Remote Installation of Millivolt Wall Switch Two remote control kits are offered. The standard ON/ To install your millivolt wall switch, an approved wall box OFF model is a WRD-1 and the thermostatic model is a should be installed in a location suitable to you.
-
Page 14: Lighting Instructions
Temco VF36RN/RNH/RP HI/LO Flame ON/OFF Adjustment Valve Control Switch ON/OFF/PILOT Piezo Blower Speed Control NOTE: Optional Remote Control Optional Gas (Optional) Receiver May be Placed on Floor Shutoff Valve Behind Cover Panel T150 Fig. 16 Fireplace control panel. For Your Safety, Read Before Lighting WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. -
Page 15: Match Lighting
Temco VF36RN/RNH/RP Match Lighting If the pilot cannot be ignited with the piezo, it can be manually lit with the use of a match and lighter rod. 1. Place the match in the holder and light. With the right hand, depress and turn the control knob counterclockwise to the PILOT position. -
Page 16: Managing Heat Output
Temco VF36RN/RNH/RP Wallboard with Marble, Managing Heat Output Brick or Stone Facing Slate or Tile Facing The heat output from the appliance can be controlled Finished Wall Finished by the position of the flue damper on vented fireplaces. Brick or... -
Page 17: Maintenance
Temco VF36RN/RNH/RP Maintenance Logs must be carefully replaced in their orignial, preset Cleaning positions (Fig. 27), to prevent the rear flames from touching any log. No other arrangement is permitted. CAUTION: Before cleaning or moving logs or other Incorrect placement can diminish combustion efficiency parts of the unit, be sure to read the section on impor- and cause sooting. -
Page 18: Troubleshooting
Temco VF36RN/RNH/RP Troubleshooting With proper installation and maintenance, your new gas in the diagnosis of problems and the corrective action to be fireplace should provide years of trouble-free service. If you taken. Any safety screen or guard removed for servicing an do experience a problem, refer to the trouble shooting guide appliance must be replaced prior to operating the appliance. -
Page 19: Repair Parts
Temco VF36RN/RNH/RP Repair Parts Always include the correct name, part number, model Temco Fireplace Products number, control type and serial number of the appliance when 410 Admiral Blvd. ordering service parts. Refer to the parts list below. Mississauga, Ontario Use manufacturer's authorized parts only. If you desire to... - Page 20 TEMCO, any component covered Pages 20 and 21 of this manual. under this warranty is found to be defective, TEMCO will, The limited warranty applies only to the original owner of at its option, repair or replace the defective component at...
-
Page 21: Installation And Startup Checklist
INSTALLATION AND STARTUP CHECKLIST Customer Copy NOTE: TEMCO Fireplace Products gas logs and fireplaces require installation by a qualified gas appliance installer. A copy of this checklist must be submitted, along with proof of purchase, when applying to Technical Services for prior written approval of warranty repair or replacement. - Page 22 INSTALLATION AND STARTUP CHECKLIST Installer’s Copy NOTE: TEMCO Fireplace Products gas logs and fireplaces require installation by a qualified gas appliance installer. A copy of this checklist must be submitted, along with proof of purchase, when applying to Technical Services for prior written approval of warranty repair or replacement.
-
Page 23: Warranty Registration
Mississauga, Ontario Canada L5T 2N6 Model # ______________________________________ Serial # ______________________________________ I certify that I have followed all codes and regulations and adhered to the TEMCO installation instructions. I have completed the proper installation and startup checklist. Installer’s Signature Print Installer’s Name... - Page 24 Temco Fireplace Products 410 Admiral Blvd. • Mississauga, Ontario, Canada L5T 2N6 • 905-670-7777...
