INSTALLER/CONSUMER
SAFETY INFORMATION
PLEASE READ THIS MANUAL
BEFORE INSTALLING AND
USING APPLIANCE
WARNING!
IF THE INFORMATION IN THIS
MANUAL IS NOT FOLLOWED
EXACTLY, A FIRE OR EXPLO-
SION MAY RESULT CAUSING
PROPERTY DAMAGE, PER-
SONAL INJURY OR LOSS OF
LIFE.
FOR YOUR SAFETY
Installation and service must be
performed by a qualified in-
staller, service agency or the
gas supplier.
WHAT TO DO IF YOU SMELL GAS:
•
Do not try to light any appliance.
•
Do not touch any electric switch;
do not use any phone in your
building.
•
Immediately call your gas
supplier from your neighbor's
phone. Follow the gas suppliers
instructions.
•
If you cannot reach your gas
supplier call the fire department.
DO NOT STORE OR USE GASO-
LINE OR OTHER FLAMMABLE
VAPORS AND LIQUIDS IN THE
VICINITY OF THIS OR ANY
OTHER APPLIANCE.
WARNING: Improper installation,
adjustment, alteration, service or
maintenance can cause injury or
property damage. Refer to this
manual. For assistance or additional
information, consult a qualified
installer, service agency or the gas
supplier.
INSTALLER: DO NOT DISCARD THIS MANUAL - LEAVE FOR HOMEOWNER
Direct Vent Zero Clearance
Gas Fireplace Heater
Models: DV1000MBN
DV1200MBN
DV1400MBN
Homeowner's Installation and
Operating Manual
U.S. Patents: 5,669,374; 5,562,088; 6,138,667: Can. Patent: 2,139,684
CFM Specialty Home Products
410 Admiral Blvd. • Mississauga, Ontario, Canada L5T 2N6 • 905-670-7777
C
US
76658 7/04 Rev. 29
Advertisement
Table of Contents
Related Manuals for Temco DV1000MBN
Summary of Contents for Temco DV1000MBN
-
Page 1: Safety Information
USING APPLIANCE Direct Vent Zero Clearance WARNING! IF THE INFORMATION IN THIS Gas Fireplace Heater MANUAL IS NOT FOLLOWED EXACTLY, A FIRE OR EXPLO- Models: DV1000MBN SION MAY RESULT CAUSING PROPERTY DAMAGE, PER- DV1200MBN SONAL INJURY OR LOSS OF DV1400MBN LIFE. -
Page 2: Table Of Contents
PLEASE READ THE INSTALLATION & OPERATING INSTRUCTIONS BEFORE USING APPLIANCE. Thank you and congratulations on your purchase of a Temco Fireplace Products fireplace. While we have written these instructions as accurately and thoroughly as possible, they may not cover every system, variation or contingency. -
Page 3: Installation & Operating Instructions
Temco DV1000/1200/1400MBN Series Installation & Operating Instructions A manufactured (mobile) home OEM installation must conform 13. This appliance may be used in a bedroom installation. with the Manufactured Home Construction and Safety Install in accordance with local building codes and Standard, Title 24CFR, Part 3280, or, when such a standard regulations. -
Page 4: Fireplace Dimensions
Temco DV1000/1200/1400MBN Series Fireplace Dimensions 4" (102mm) Dia. Rough 7" (178mm) Dia. Opening Depth Bottom Gas Line Access S - Rough Opening Width Rough Opening Height Gas Line J Box J Box Access Access Access Line Access NOTE: Flex pipe diameters are 4”... -
Page 5: Locating Your Fireplace
Temco DV1000/1200/1400MBN Series Locating Your Fireplace 1” (25mm) Minimum Air Space Clearance U584-1 to Combustible Materials Fig. 4 Locate gas fireplace. A) Flat on wall B) Cross Corner C) As an Island Vent “X” D) As a room divider E) Flat on wall corner... -
Page 6: Clearance To Combustibles
Temco DV1000/1200/1400MBN Series 5. Drywall can be extended flush on the bottom, top and to the outermost part of the sides of the fire- place. 6. If you are installing the top vent unit with a 90° elbow installed, the minimum clearance to combus- tibles directly above the 90°... -
Page 7: Gas Specifications
1/2psig (3.5 KPa). 8. The appliance must be isolated from the gas supply DV1000MBN / DV1000MBP / DV1200MBN / piping system by closing its equipment shut off valve during any pressure testing of the gas supply... -
Page 8: General Venting
NOTE: Local codes may require different clearances. 1. Temco 4” x 7” dia. flex vent. 2. Temco TDV series 4” x 7” dia. rigid vent. It is recommended that the termination not be located within 24" (305mm) of garden sheds, fences, decks, 3. -
Page 9: General Venting Information - Termination Location
Temco DV1000/1200/1400MBN Series General Venting Information - Termination Location INSIDE CORNER DETAIL Fixed Fixed Closed Closed Fixed Operable Closed AREA WHERE TERMINAL IS NOT PERMITTED VENT TERMINATION AIR SUPPLY INLET CFM145a Canadian Installations US Installations A = Clearance above grade, veranda, porch, 12”... -
Page 10: Termination Clearances
Temco DV1000/1200/1400MBN Series Termination Clearances Termination clearances for buildings with combustible and noncombustible exteriors. Recessed Location Inside Corner Outside Corner Combustible 6"(152mm) Combustible 6"(152mm) Noncombustible 2"(50mm) Noncombustible 2"(50mm) Balcony - Balcony - with perpendicular side wall with no side wall C = Maximum depth of 48"... -
Page 11: Sidewall (General)Venting Information
Temco DV1000/1200/1400MBN Series 4. Determine the permitted range of horizontal termi- nation arrangement by using chart above and deducting 3’ (914mm) from the maximum horizontal distance for the second 90° elbow. Vent Opening for Combustible Wall 9 " (248mm) 5 ”... -
Page 12: Sidewall (Horizontal) Venting
Temco DV1000/1200/1400MBN Series Horizontal Vent Kits • For 4” x 7” flex, the 7” flex has an outside diameter of 7 ” (191mm) and if installed in a chase the ♦ CDV-HSK (Round Termination Cap) inside diameter of the chase should be 9 ”... - Page 13 Temco DV1000/1200/1400MBN Series Step 3: Apply silicone sealant to 7” outer pipe on Firestop/Wall Sleeve cap. (Included with HFTK) Exterior Wall GFP74FV3 (3’ Step 4: Slide 7” outer flex over inlet and secure with VEF (or BEF) (914mm) Flex Pipe Vinyl (or Brick) band clamp.
-
Page 14: Flex Vent Through The Roof (Vertical) Applications
Temco DV1000/1200/1400MBN Series Flex Vent Through the Roof (Vertical) Applications (35’ Max.) Roof All models are approved for: 1. Vertical venting up to 35’ (10.7m) with 7" x 4" flex. 6’ (1.8m) 2. Multiple bends allowed. See section on General Maximum Venting. -
Page 15: Tdv Series Direct Vent System Installation
TDV Series Direct Vent System Installation Dia. • The TDV series vent system is specifically approved 7” (178mm) Dia. only for Temco Direct-Vent fireplace models with a Vent Pipe 4” (102mm) diameter flue and a 7” (178mm) diam- Assembly (VSK7MH-2) eter inlet vent system. -
Page 16: Through The Roof (Vertical) Venting
Temco DV1000/1200/1400MBN Series NOTICE: Flexible and rigid vent system components Through the Roof (Vertical) Venting are not interchangable unless otherwise specified in When the venting penetrates a roof, the system must the venting instructions. be insalled in accordance with the current CSA B149.1... - Page 17 Temco DV1000/1200/1400MBN Series sealants are not required). Never use screws in vent ATTENTION: Vent terminal flue and inlet pipes must systems longer than 1” (25mm). overlap last vent section a minimum of 1” (25mm). 7. Vent sections and elbows may be rotated 360° prior...
-
Page 18: Venting Components
(Used with 7” dia. pipe (75783) system only) (76049) system only) (76048) T199 Temco Flex Vent Termination Kits Available Square Horizontal Cap (uses 7/4 Flex) HFTK Round Hor. Term. Cap (High Wind) (Includes 7/4 Flex x 3 ft. long) CDV-HSK Round Hor. -
Page 19: Operating Instructions
The fireplace is shipped without the louvre assemblies and install the door with this area at the top. installed. Various styles and finishes are available as options. Contact your nearest Temco dealer/distributor Glass Door Removal Procedure for information on the Louvre Kits available. -
Page 20: Log Installation
Push log back as far as it will go. TL119 4. The center log should be placed on the center log Fig. 32 Correct log placement for DV1000MBN and DV1200MBN. supports, slots aligned with tabs, and log placed rearward. -
Page 21: Thermostatic Fan Kit - Optional
Temperature Sensor Speed Control Switch Black Volt TL121 White Fig. 34 DV1000MBN and DV1200MBN logs in final posi- Green tion. T173 Fig. 36 Fan wiring diagram. Twig Back CAUTION: Should this fan require ser- vicing, the power supply must be discon- Front Log nected. -
Page 22: Managing Heat Output
Temco DV1000/1200/1400MBN Series Thermopile Fan Operation Pilot The fan operates automatically - turn the knob on the Ignitor Thermocouple speed control to adjust to the desired speed. The fan will turn on as the fireplace comes up to operating Pilot Screw temperature. -
Page 23: Lighting & Operating Instructions
Temco DV1000/1200/1400MBN Series Lighting and Operating Instructions FOR YOUR SAFETY READ BEFORE LIGHTING WARNING:If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This heater has a pilot which must be lit manu- instructions. -
Page 24: Troubleshooting
Temco DV1000/1200/1400MBN Series Troubleshooting SIT Millivolt Valve NOTE: Before troubleshooting the gas control system, be sure external shut off is in the “ON” position. WARNING: Before doing any gas control service work, remove glass front! Table 1 Valve Type Main Operator... - Page 25 Temco DV1000/1200/1400MBN Series System Checks (continued) Problem Possible Cause Solution Defective thermocouple. Verify that thermocouple is not kinked or damaged. Check (mv Plus systems) open circuit voltage of thermocouple. Voltage should be between 18mv and 28mv. If voltage is less than 14mv, replace thermocouple.
- Page 26 Temco DV1000/1200/1400MBN Series System Checks (continued) Problem Possible Cause Solution Thermo-generator output After the pilot has been lit for approximately three voltage not within design minutes, and only the thermo-generator wire connected parameters. to the main operator head, measure the voltage across TPTH and TP.
-
Page 27: Fuel Conversion Instructions
4. Using a suitable tool replace natural orifice #46 with valve. propane orifice #56 for model DV1000MBN or replace natural orifice #45 with propane orifice #55 Installer Notice: These instructions must be left for model DV1200MBN, or replace natural orifice with the appliance. - Page 28 Temco DV1000/1200/1400MBN Series Model Number Conversion Parts Included with Fireplace DV1000MBN DV1200MBN DV1400MBN Main Burner Orifice - LP #56 - PCOA070H21 #55 - PCOA070H19 #54 - 76759 Label, Conversion 77697 77698 77699 Pilot, Orifice - LP 76263 76263 76263 Conversion Pressure Regulator Assembly - LP...
- Page 29 Temco DV1000/1200/1400MBN Series Pressure ranges are: Gas Supply Pressure (inches w.c.) Minimum Normal Maximum LP (Propane) 10.8 11.0 14.0 Manifold Pressure (inches w.c.) Nornal (HI) Normal (Low) LP (Propane) 10.0” 6.3” Manifold pressure can be measured by using a 5/16”...
-
Page 30: Maintenance
Temco DV1000/1200/1400MBN Series Maintenance Once installed, the unit should be operated at least High Altitude three (3) times to ensure that all is in working order. When installing this fireplace at an elevation between 0 NOTE: Manufacturing oils will smoke during initial and 2000 feet (0 - 610m) in the USA and 0 and 4500 firing of appliance. - Page 31 Temco DV1000/1200/1400MBN Series Cleaning After the logs are removed allowing access to the burner area, use a vacuum cleaner to carefully remove This unit should be cleaned and serviced by a Qualified dust and loose particles from the base, logs and from Gas Technician at least annually.
- Page 32 Temco DV1000/1200/1400MBN Series Normal and High Direct Vent Units - Inputs - Orifice Size - Altitude BTU/Hr BTU/Hr Manifold Pressure Orifice 0 - 2000ft. Altitude in USA Model Min. Input Max. Input @ Max. Orifice 0-4500ft Altitude in Canada DV1000MBN...
-
Page 33: Replacement Parts
Temco DV1000/1200/1400MBN Series Replacement Parts DV1000MBN, DV1200MBN, DV1400MBN Description DV1000MBN DV1200MBN DV1400MBN Burner 75470 75470 75470 Gasket Tape 5/8” Wide 75279 75448 75447 Gas Valve LP (SIT) 76448 76448 76448 Gas Valve NG (SIT) 76449 76449 76449 Glass Door Assembly... -
Page 34: Warranty
Limited Warranty TEMCO Fireplace Products Direct Vent Gas Fireplaces and Startup Checklist, a copy of which must be This warranty is limited to TEMCO Fireplace Products submitted along with proof of purchase, to obtain Direct Vent Gas Fireplaces (henceforth, Product) manu-... -
Page 35: Installation And Startup Checklist
INSTALLATION AND STARTUP CHECKLIST Customer Copy NOTE: TEMCO Fireplace Products gas logs and fireplaces require installation by a qualified gas appliance in- staller. A copy of this checklist must be submitted, along with proof of purchase, when applying to Technical Ser- vices for prior written approval of warranty repair or replacement. - Page 36 INSTALLATION AND STARTUP CHECKLIST Installer’s Copy NOTE: TEMCO Fireplace Products gas logs and fireplaces require installation by a qualified gas appliance installer. A copy of this checklist must be submitted, along with proof of purchase, when applying to Technical Services for prior written approval of warranty repair or replacement.
-
Page 37: Warranty Registration
