Electric Fireplace
Model: TEF26
Installation Instructions and
Homeowners Manual
www.temcofireplaces.com
TEF33
TEF36
10007169 6/05 Rev. 1
Advertisement
Table of Contents
Related Manuals for Temco TEF26
Summary of Contents for Temco TEF26
-
Page 1: For Your Safety
PLEASE READ THIS MANUAL BEFORE INSTALLING AND USING APPLIANCE Electric Fireplace WARNING! IF THE INFORMATION IN THIS Model: TEF26 MANUAL IS NOT FOLLOWED EXACTLY, AN ELECTRICAL SHOCK TEF33 OR FIRE MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. -
Page 2: Table Of Contents
Table of Contents PLEASE READ THE INSTALLATION & OPERATING INSTRUCTIONS BEFORE USING THIS APPLIANCE Thank you and congratulations on your purchase of a CFM Specialty Home Products electric fireplace. IMPORTANT: Read all instructions and warnings carefully before starting installation. Failure to follow these instructions may result in a possible electric shock, fire hazard and will void the warranty. -
Page 3: Installation Instructions
Installation Instructions General have to use an extension cord, the cord shall be 14 ga 1. Read all instructions before using this appliance. minimum size and rated not less than 2025 Watts. The 2. This appliance is hot when in use. To avoid burns, do not extension cord must be a three wire cord with grounding let bare skin touch hot surfaces. -
Page 4: Fireplace Dimensions
Fireplace Dimensions 1” (25 mm) Ref. TEF26 TEF33 TEF36 27¹⁄₂” (699 mm) 34¹⁄₂” (876 mm) 37¹⁄₂” (953 mm) 25¹⁄₄” (641 mm) 29³⁄₄” (743 mm) 33¹⁄₄” (845 mm) 26¹⁄₄” (667 mm) 33¹⁄₄” (845 mm) 36¹⁄₄” (921 mm) 24¹⁄₂” (622 mm) 29”... -
Page 5: Electrical Connection
This instruction is intended as a guide for replacing the 90° terminal (on the control board side, it ends on power cord supplied with Models TEF26/33/36 electric your right hand side). Similarly, connect the neutral fireplace with direct (hard) wiring. -
Page 6: Service Instructions
Service Instructions WARNING: Disconnect power before attempting any maintenance or cleaning to reduce the risk of fire, electrical shock or personal injury. Replacing Front Cover Access to heater/fan 1. Turn off power to the unit. Remove Screws 2. Let fireplace cool if it has been operating. 3. -
Page 7: Replacing The Light Bulbs
7. Looking into the opening of the unit under the Replacing the Light Bulbs ember bed, visually locate the light bulbs. 8. Remove the light bulbs by unscrewing them out of Depending on your model, the fireplace uses two (2) or the bases, turning them counterclockwise. -
Page 8: Electrical Wiring Diagram
POWER CORD MOTOR WHITE BLACK LIGHT RETURN LIGHT CIRCUIT BOARD NEUTRAL GROUND COMM. HEATER MOTOR RETURN LINE NEUTRAL WARNING: Disconnect Power Before Servicing. NOTE: TEF26 Units have AVERTISSEMENT: Debrancher la source d’alimentation avant le service. only 2 light bulbs 10007169... -
Page 9: Operating Instructions
Operating Instructions All of the fireplace control functions can be accessed in • As a visual effect - only flame effect is on, the heater two (2) ways: is off. We recommend this mode for warm weather application, when you want the ambiance of a fire, •... -
Page 10: Replacement Parts
216mm [8 1/2"] (DISTANCE BETWEEN TWO SOCKETS} 305mm [12"] CFM Specialty Home Products reserves the right to make changes in design, materials, specifications, prices and discontinue colors and prod- ucts at any time, without notice. TEF26/33/36 Electric Fireplace Ref. Description TEF26 TEF33 TEF36 1. -
Page 11: Warranty
Installation and respect to the sale of this Temco Fireplaces product. Operating instructions furnished with the product. Any 9. The warranties as outlined within this document do not... - Page 12 CFM Specialty Home Products 410 Admiral Blvd. • Mississauga, Ontario, Canada L5T 2N6 • 905-670-7777 www.temcofireplaces.com...
