- Page 1 ZEKTOR DVS5.1 DVI Video / Audio Switch Owner’s Manual www.zektor.com Rev: 2 01/19/05...
-
Page 2: Important Safety Instructions
Important Safety Instructions! Read all instructions for prior to installation of your product. Retain this User's Manual for future reference. Adhere to all safety and operation instructions. Before cleaning this product, unplug from the wall outlet. Do not use liquid cleaning products. Use a damp cloth for cleaning. -
Page 3: Table Of Contents
Restoring the DVS5.1 to Factory Defaults ....... . . 15... -
Page 4: A Dvs5.1 Overview
The RS-232 module must be purchased separately. Features The DVS5.1 is a DVI-D only switch. This means it will pass digital video signals, but not the analog video signals that are present with DVI-A or DVI-I. The rear panel connectors can accept any type of cable for your convenience. -
Page 5: Front Panel Operations
Press any one of the five input select buttons to switch the DVS5.1 to the selected input. If the DVS5.1’s power is turned off, selecting any one of the five inputs will cause the DVS5.1 to power on and switch to the selected input. -
Page 6: Using The Dvs5.1 With A Remote Control
Remote operations of the DVS5.1 are accomplished through the use of just about any remote con- trol. A remote control is not supplied with the DVS5.1, yet the versatile programming modes of the DVS5.1 allows the DVS5.1 to work with virtually any remote control. The next section "Program- ming your Remote Control"... -
Page 7: Programming Your Remote Control
The simplest way to begin using the DVS5.1 is to program your Universal Remote control to act like the remote used to control a Awia DVD. Once this is done you will be able to immediately start using your DVS5.1. -
Page 8: Using Alternate Remote Codes
See the next section. Or teach the DVS5.1 a new set of codes, See: "Learning New Remote Codes" on page 10. -
Page 9: Searching For A Component Code In Your Remote
Assuming you do not have a remote listed in this user manual you will have to follow your remote control’s programming sequences to find a compatible component that the DVS5.1 understands. Or you can also go to the section "Learning New Remote Codes" on page 10, to teach the DVS5.1 new keys for individual commands. -
Page 10: Learning New Remote Codes
DVS5.1 functions to other keys on your remote, the DVS5.1 can be taught to use new keys. To teach the DVS5.1 to respond to new keys, you need to have the remote control you want to use ready, and setup in the manner you want it to be used. - Page 11 4 The Power indicator blinks slowly, and input 2 is selected. ZEKTOR Audio Press the key on your remote that you want to use as the new key for S ELECT BLINK 5 The Power indicator blinks slowly, and input 3 is selected.
-
Page 12: Remote Control Learning Caveats
When programming the DVS5.1, if the IR indicator light blinks, and the DVS5.1 moves on to the next step, then the remote controller’s key code has been accepted. If the IR indicator does not blink, it indicates the DVS5.1 does not understand that particular manufactures code and you will... -
Page 13: Bright / Dim / Auto-Dimming Modes
Setting the Display intensity modes of the DVS5.1 The front panel display of the DVS5.1 can be set to Bright, Dim or an Auto-dimming mode where the display brightens for 4 seconds after any function is selected and then auto-dims. -
Page 14: Setting Power On Defaults
(by plugging the AC wall adapter back in), it will power up in a user settable default mode. This is useful in situations where the DVS5.1 is externally switched by a power strip. The factory default settings for initial power on are: •... -
Page 15: Restoring The Dvs5.1 To Factory Defaults
Restoring the DVS5.1 to the factory defaults Resetting the DVS5.1 to the factory defaults is done by removing power to the DVS5.1. The AC wall adapter must be unplugged, so that the DVS5.1 is completely without power. The SETUP key is then pressed and held while power is restored to the DVS5.1. -
Page 16: Typical Application
SAT 2 HD-DVR DLP Projector with HDCP The above example shows DVS5.1 setup to select between 5 different DVI devices. The DVI output is connected to a DLP projector, and the audio out is connected to a Surround Sound Processor. -
Page 17: Typical Applications (Cont'd)
The DVS5.1 can be mounted in a standard 19" equipment rack with the optional rack mount kit. In addition to installing the rack mount ears to the side of the DVS5.1, you will have to remove the feet from the bottom of the switch. To remove the feet, peel back the felt pads, and remove the screw... -
Page 19: Warranty Information
ZEKTOR, LLC warrants this product against defects in material and workmanship under normal use and service for one year from the original date of purchase. ZEKTOR, at its option, shall repair or replace the defective unit covered by this warranty. -
Page 20: Customer Service Contact Information
Customer Service Contact Information ZEKTOR, LLC 12675 Danielson Court Suite 401 Poway, CA 92064 Phone: (858) 748-8250 Email: customerservice@zektor.com...
