- Page 1 ZEKTOR MAS3 Multi-channel Audio Switch Owner’s Manual www.zektor.com Rev: 2 03/12/04...
-
Page 2: Important Safety Instructions
Important Safety Instructions! Read all instructions for prior to installation of your product. Retain this User's Manual for future reference. Adhere to all safety and operation instructions. Before cleaning this product, unplug from the wall outlet. Do not use liquid cleaning products. Use a damp cloth for cleaning. - Page 3 Operating the MAS3 is straight forward and simply a matter of plugging the MAS3’s power supply into an available A.C. outlet, and then plugging the MAS3’s power supply into the back of the MAS3. To operate the MAS3 manually, press the power switch, located on the very left of the MAS3 to cy- cle power.
- Page 4 Remote operations of the MAS3 are accomplished through the use of just about any remote control. A remote control is not supplied with the MAS3, yet the versatile programming modes of the MAS3 allows the MAS3 to work with virtually any remote control. The next section "Programming your Re- mote Control"...
-
Page 5: Programming Your Remote Control
The simplest way begin using the MAS3, is to program your Universal Remote control to act like a Symphonic TV. Once this is done you will be able to immediately start using your MAS3. Check your remote’s user manual for instructions on programming your remote control. -
Page 6: Using Alternate Component Keys On Your Remote
You must then teach the MAS3 to respond to the same set of alternate component codes. Programming your remote to different components The MAS3 will respond to eight different pre-programmed component codes, they are: Symphonic TV, Hatachi Satellite, Sony TV, Yamaha VCR, Go Video VCR, Awia DVD, Nakamichi Receiver and a Jerrold Cable Box. -
Page 7: Searching For A Component Code In Your Remote
ZEKTOR ZEKTOR ZEKTOR Searching for a component code in your remote Assuming you do not have a remote listed in this user manual you will have to follow your remote controls programming sequences to find a compatible component that the MAS3 understands, or you can go to the section "Learning New Remote Codes"... -
Page 8: Learning New Remote Codes
Teaching the MAS3 to use new remote control keys If your remote does not have one of the pre-programmed component codes, or you simply want to re-map the MAS3 functions to other keys on your remote, the MAS3 can be taught to use new keys. To teach the MAS3 to respond to new keys, you need to have the remote control(s) you want to use ready, and setup in the manner you want it to be used. - Page 9 ZEKTOR BLINK ZEKTOR BLINK ZEKTOR BLINKS ZEKTOR BLINKS ZEKTOR BLINKS ZEKTOR BLINKS ZEKTOR BLINKS Press the key on your remote that you want to use as the new key for S ELECT 5 The Power indicator blinks slowly, and input 3 is selected. Press the key on your remote that you want to use as the new key for S ELECT...
-
Page 10: Remote Control Learning Caveats
ZEKTOR BLINKS ZEKTOR Remote Control Learning Caveats Some component’s control codes will work better than others. We’ve designed the MAS3 to work with a great majority of codes, however a few brands use non-standard ways of transmitting their component’s codes that may not be compatible with the MAS3. In these somewhat rare circum- stances you will have to program your remote control to a different manufacturer’s code, and/or use different buttons on your remote. -
Page 11: Bright / Dim / Auto-Dimming Modes
Setting the Display intensity modes of the MAS3 The front panel display of the MAS3 can be set to Bright, Dim or an Auto-dimming mode where the display brightens for 4 seconds after any function is selected and then auto-dims. Setting the mode is simply a matter of toggling between the three modes: •... -
Page 12: Setting Power On Defaults
The MAS3 power on default mode When toggling between Standby mode and PowerOn the MAS3 will remember all it’s current set- tings. After completely powering down the MAS3 (by unplugging the AC wall adapter), upon restor- ing power (by plugging the AC wall adapter back in), it will power up in a user settable default mode. This is useful in situations where the MAS3 is externally switched by a power strip. - Page 13 GREEN three times indicating the MAS3 has been reset to its factory defaults. The MAS3 factory defaults, are: • Control codes used are the Symphonic TV codes. • Default power up mode is standby. • Default selected input when powered on is input 1.
-
Page 14: Typical Application
Typical application of Multi-channel Audio Switching SACD player SACD Player # 2 DVD-A Player MAS-3 CENTER CENTER CENTER input CENTER To 6 channel Pre-Amp... -
Page 15: Warranty Information
Warranty Information Warranty Policy ZEKTOR, LLC warrants this product against defects in material and workmanship under normal use and service for one year from the original date of purchase. ZEKTOR, at its option, shall repair or replace the defective unit covered by this warranty. In order to keep this warranty in effect, the product must have been handled and used as prescribed in the instructions accompanying this warranty. -
Page 16: Customer Service Contact Information
Customer Service Contact Information: ZEKTOR, LLC 12675 Danielson Court Suite 401 Poway, CA 92064 Email: customerservice@zektor.com...
