Video Display

The following table lists some common video configuration problems.
Problem
Display is black, not synchronized, or
distorted.
Monitor does not support a selected
resolution or refresh rate.
Two or three RealiZm II cards installed,
but you cannot select the Multiple Screen
option.
A dim line, rolling vertically, is visible on
the screen (for multiple screens only).

Obtaining a Usable Video Resolution

The system operates in VGA mode when the video display driver is not running to
accommodate all monitor types. VGA mode is used during initial installation of the video
display driver and when experiencing video problems. If you select a resolution that causes
the monitor to display incorrectly, do not press
operating system. Instead, use the Last Known Good option to return to the last known good
configuration recorded by Windows NT.
To use the Last Known Good option:
1. Restart the system.
2. Press the space bar at the following prompt:
Press space bar NOW to invoke the Last Known Good Menu
If using the Last Known Good option fails to correct the video display problems, you can
obtain a functional video resolution by restarting the system in VGA mode.
Action
Restart Windows NT in VGA mode.
Select a supported resolution and refresh rate.
Verify proper installation of all RealiZm II cards
(only one card was detected).
Verify proper installation of the clock sync
cable.
+ + to log on to the Windows NT
CTRL ALT DEL
