RealiZm II Graphics Configurations

RealiZm II graphics configurations are designated by the maximum resolution supported, and
by the support of texture memory and geometry acceleration:
u
The last two digits of the number denote the maximum supported resolution. For
example, ZX13 and VX113 indicate support for a maximum resolution of 1.3 Mpixels.
u
The -T suffix denotes support for texture processing.
u
The -G suffix denotes support for optional geometry acceleration.
The available RealiZm II graphics configurations are as follows:
Designation
ZX13
ZX13-T
ZX13-G
ZX13-GT
VX113-T
VX113-GT
VX113 AGP-T
VX113 AGP-GT
ZX25, VX25
ZX25-T, VX25-T
ZX25-G, VX25-G
ZX25-GT, VX25-GT

Connecting Monitors to RealiZm II Cards

If your workstation was shipped with one or more RealiZm cards installed, the video display
driver is already installed. All you need to do to use your workstation is to connect the
monitors to it, power it on, and start Windows NT. Use the following instructions to connect
monitor cables as required.
CAUTION On a ZX13, ZX25, or VX25, do not connect a monitor cable to the black VGA input port. If you
do, the video will not display.
NOTE The VX113 and VX113 AGP do not have a VGA input port.
Configuration
1.3 Mpixels
1.3 Mpixels, texture processing
1.3 Mpixels, geometry acceleration
1.3 Mpixels, geometry acceleration, texture processing
1.3 Mpixels, texture processing
1.3 Mpixels, geometry acceleration, texture processing
1.3 Mpixels, texture processing
1.3 Mpixels, geometry acceleration, texture processing
2.5 Mpixels
2.5 Mpixels, texture processing
2.5 Mpixels, geometry acceleration
2.5 Mpixels, geometry acceleration, texture processing
