Hardware Installation

2-3.1 CPU Installation

Your SY-7VBA133U motherboard comes with a CPU retention set kit.
The retention set is used to hold the processor attached to the Socket 370
CPU connector on the motherboard.
Mark your CPU Frequency:
your CPU that should be clearly marked on the CPU cover.
FSB 66MHz
400MHz ( 66 x 6.0 )
433MHz ( 66 x 6.5 )
466MHz ( 66 x 7.0 )
FSB 100MHz
500MHz(100x 5.0)
550MHz(100x 5.5)
FSB 133MHz
533MHz(133x 4.0)
600MHz(133x 4.5)
CPU Mount Procedure:
processor that you have purchased separately, follow these instructions.
1. Lift the socket handle up to a vertical position.
500MHz ( 66 x 7.5 )
533MHz ( 66 x 8.0 )
566MHz ( 66 x 8.5 )
600MHz(100x 6.0) 700MHz(100x 7.0)
650MHz(100x 6.5) 750MHz(100x 7.5)
667MHz(133x 5.0) 800MHz(133x 6.0)
733MHz(133x 5.5) 866MHz(133 x6.5)
To mount the Pentium®, Celeron
Record the working frequency of
600MHz ( 66 x 9.0 )
633MHz ( 66 x9.5 )
667MHz ( 66 x10.0 )
800MHz(100x 8.0)
850MHz(100x 8.5)
933MHz(133x 7.0)
1GHz (133 x 7.5)
