BIOS Setup Utility SY-7VBA133U

2-3.6 Quick BIOS Setup

This Motherboard does not use any hardware jumpers to set the CPU
frequency. Instead, CPU settings are software configurable with the BIOS
[SOYO COMBO FEATURE]. The [SOYO COMBO FEATURE]
combines the main parameters that you need to configure, all in one menu,
for a quick setup in BIOS.
After the hardware installation is complete, turn the power switch
on, then press the <DEL> key during the system diagnostic checks
to enter the Award BIOS Setup program. The CMOS SETUP
UTILITY will be shown on the screen. Then, follow these steps to
configure the CPU settings.
Step 1. Select [STANDARD CMOS SETUP]
Set [Date/Time] and [Floppy drive type], then set [Hard Disk Type] to
"Auto".
Step 2. Select [LOAD OPTIMIZED DEFAULTS]
Select the "LOAD OPTIMIZED DEFAULTS" menu and type "Y" at the
prompt to load the BIOS optimal setup.
Step 3. Select [SOYO COMBO FEATURE]
Set the [CPU Frequency Select] field to "Manual", to be able to change
the CPU frequency 1 MHz stepping.
Step 4. Select [SAVE & EXIT SETUP]
Press <Enter> to save the new configuration to the CMOS memory, and
continue the boot sequence.
42
