Hardware Installation
(2) Chassis Cooling Fan
Some chassis also feature a cooling fan. This Motherboard features a
CHAFAN connector to provide 12V power to the chassis fan. Connect the
cable from the chassis fan to the CHAFAN 3-pin connector. Install
according to the following pin assignment:
Note: CPUFAN must be installed for this Motherboard, CHAFAN is
optional.
2-3.3.6 AGP VGA Card
Insert the AGP VGA card into the AGP slot. Then connect the monitor
information cable to the AGP card back plane external connector.
Chassis Cooling Fan
CHAFAN Pin Assignment
3
2
1
SENSOR
12V
GND
38
SY-7VBA133U
