14.5.8 NORTH REFERENCE

> 'MENU' 1 sec. + "SYSTEM SETUP" + 'ENTER' + "UNITS SETUP" + 'ENTER' + "NORTH REFER-
ENCE" + 'ENTER'
The North Reference for calculations can be shown as Magnetic or True (Mag-
netic uses an automatic adjustment for local magnetic variation).
The North Reference used for wind computations and runway information is
always Magnetic; all other heading, bearing and Track computations are based
on the user-selected reference. The default setting is Magnetic.

14.5.9 COORDINATE SYSTEM

> 'MENU' 1 sec. + "SYSTEM SETUP" + 'ENTER' + "UNITS SETUP" + 'ENTER' + "COORDINATE
SYSTEM" + 'ENTER'
Sets the display of the Latitude/Longitude coordinates system among: DDD
MM SS (Degrees, Minutes, Seconds); DDD MM.mm (Degrees, Minutes - to
two decimals); DDD MM.mmm (Degrees, Minutes - to three decimals); UTM,
OSGB. The default setting is DDD MM.mm.
14.6 DATE & TIME SET-UP
These functions control how the EKP-IV displays time and date settings.
> 'MENU' 1 sec. + "SYSTEM SETUP" + 'ENTER' + "DATE & TIME SETUP" + 'ENTER'

14.6.1 TIME FORMAT

> 'MENU' 1 sec. + "SYSTEM SETUP" + 'ENTER' + "DATE & TIME SETUP" + 'ENTER' + "TIME
FORMAT" + 'ENTER'
Using the cursor key select the desired setting and press 'ENTER'.
Time can be displayed as UTC (Zulu time) 12 hour or 24 hour local time. The
default setting is 24/Local.
If you select a local time display, continue with the next step.

14.6.2 LOCAL TIME DIFFERENCE

If you select local time above, you must key in an offset from UTC. The cor-
rect time difference must be entered to calculate the local time.
> 'MENU' 1 sec. + "SYSTEM SETUP" + 'ENTER' + "DATE & TIME SETUP" + 'ENTER' + "LOCAL
TIME DIFFERENCE" + 'ENTER'
After pressing 'ENTER' a window appears; using the cursor key, select the
difference between local time and UTC to the nearest 30 Minutes. Press 'EN-
TER' to activate.
NOTE
If you are unsure what the time difference is for your area, get a position fix using the UTC format.
Display the Location page and note the displayed time. Compare UTC to your local time and note
