Use the cursor key to select and 'ENTER' to accept. The Off selection of this
menu will turn all beeper sounds Off. The default setting is On.

14.1.2 Scale format

Selects the desired setting for display of the map scale in the Data Window
field.
> 'MENU' 1 sec. + "SYSTEM SETUP" + 'ENTER' + "GENERAL SETUP" + 'ENTER' + "SCALE
FORMAT" + 'ENTER'
The selection options are:
BAR - the width of the screen is equal to the bar length times the number
displayed.
LEVEL - a letter associated with C-MAP's chart cell level is displayed.
WIDTH - the width of the screen is displayed.
Use the cursor key to select and 'ENTER' to accept. The default setting is Bar.

14.1.3 Language

Selects the language in which you wish menu information to be displayed (i.e.
screen labels, menus and options). Map detail will remain in English.
> 'MENU' 1 sec. + "SYSTEM SETUP" + 'ENTER' + "GENERAL SETUP" 'ENTER' + "LANGUAGE" +
'ENTER'
Use the cursor key to select and 'ENTER' to accept. The default setting is
English.

14.1.4 Military Frequency

The display of Military Frequency data can be set to ON or OFF (this data is
found in
European Database cards).
> 'MENU' 1 sec. + "SYSTEM SETUP" + 'ENTER' + "GENERAL SETUP" + 'ENTER' + "MILITARY
FREQUENCY" + 'ENTER'
Use the cursor key to select and 'ENTER' to accept. The default setting is Off.

14.2 FIX SET-UP

The Fix Setup sub-menu contains options relating to GPS data input and display.
> 'MENU' 1 sec. + "SYSTEM SETUP" + 'ENTER' + "FIX SETUP" + 'ENTER'

14.2.1 FIX SOURCE

The EKP-IV uses positioning information provided by the internal GPS-re-
ceiver or by an external NMEA 0183, external Air Data, or External RNAVdata
string.
