User Guide for the SoundStation IP 7000 Phone
Note
1 - 10
www.InternetVoipPhone.co.uk | sales@internetvoipphone.co.uk | 0800 088 4846
To connect to audio from a mobile phone:
>>
Connect one end of the optional Mobile Phone Cable to the headset jack on
your mobile phone, and connect the other end to the 2.5mm audio
connector on your conference phone.
If your conference phone setup has two connected phones, you can attach the
Mobile Phone Cable to either conference phone.
For information on using your conference phone with a mobile phone
connection, see Using Computer or Mobile Audio with the Conference Phone
on page 4-1.
To connect to audio from a computer calling application:
>>
Connect one end (the end with two connectors) of the Computer Calling
Cable (contained in the optional Computer Calling Kit) to the sound card
on your computer, and connect the other end to the 2.5mm audio
connector on your phone.
For information on using your phone with a computer calling application, see
Using Computer or Mobile Audio with the Conference Phone

Audio Connectors on Multi-Interface Module

The Multi-Interface Module has various connectors and ports to connect
wireless (lapel) microphones, speakers, and recording devices and computers
(to record phone calls). To attach audio components to the Multi-Interface
Module, see your system administrator.
on page 4-1.
