EDID Control Settings

At times, your HDMI sources and display may not synchronize properly.
This is when EDID* control should be utilized. KD-HDDA Pro
Distribution Amps feature an internal library of EDID settings to ensure
your HDMI source's output is compatible with the display devices.
Please reset the unit by either unplugging and plugging the HDMI
connections, or via a power cycle for the new settings to take effect.
Rotary EDID Settings:
KD-HDDA1x2Pro
EDID Settings
0
Copy EDID from
HDMI Output 1
1
1080i, 2Ch Audio
2
1080i, Dolby/DTS 5.1
3
1080i, 2ch Audio
4
1080p, Dolby/DTS 5.1
5
1080p, HD Audio
1080p, 2ch Audio
6
3D, 2ch Audio
7
8
3D, Dolby/DTS 5.1
9
3D, HD Audio
A
1280x1024 DVI
B
1920x1080 DVI
C
1920x1200 DVI
D
1080p, 2Ch Audio
E
1080p, 2Ch Audio
F
Copy EDID from
HDMI Output 2
Example of EDID Auto Select:
If one of your system's displays supports 1080p and the second display only supports up to
1080i (does not support 1080p), then the highest common EDID format supported is 1080i. By
choosing the Auto Select EDID Setting, your KD-HDDA Pro unit will inform your source device to
output 1080i in order to ensure all displays receive a supported signal.
* EDID (Extended display identification data) is a data structure provided
by a display to describe its capabilities to a source device.
KD-HDDA1x3Pro
EDID Settings
0
Copy EDID from
HDMI Output 1
1
1080i, 2Ch Audio
2
1080i, Dolby/DTS 5.1
3
1080i, 2ch Audio
4
1080p, Dolby/DTS 5.1
5
1080p, HD Audio
1080p, 2ch Audio
6
3D, 2ch Audio
7
8
3D, Dolby/DTS 5.1
9
3D, HD Audio
A
1280x1024 DVI
B
1920x1080 DVI
C
1920x1200 DVI
D
1080p, 2Ch Audio
E
Copy EDID from
HDMI Output 3
F
Copy EDID from
HDMI Output 2
Rotary EDID Control Switch
KD-HDDA1x4Pro
EDID Settings
0
Copy EDID from
HDMI Output 1
1
1080i, 2Ch Audio
2
1080i, Dolby/DTS 5.1
3
1080i, 2ch Audio
4
1080p, Dolby/DTS 5.1
5
1080p, HD Audio
1080p, 2ch Audio
6
3D, 2ch Audio
7
8
3D, Dolby/DTS 5.1
9
3D, HD Audio
A
1280x1024 DVI
B
1920x1080 DVI
C
1920x1200 DVI
D
Copy EDID from
HDMI Output 4
E
Copy EDID from
HDMI Output 3
Copy EDID from
F
HDMI Output 2
