Introduction

Key Digital Phantom Series
®
to offer the best in quality, performance, and reliability while providing a cost effective HDMI/
DVI distribution solution. The KD-HDDA1x2Pro; KD-HDDA1x3Pro; KD-HDDA1x4Pro HDMI
Distribution Amplifiers provide single input to multiple output distribution and maintain
crystal-clear, pristine picture and sound quality. Phantom Series
a transparent solution for all digital video/audio distribution applications and support all HD
and SD video standards, including 1080p/60. KD-HDDA Pro Distribution Amplifiers feature
status-monitoring LEDs and are capable of separating HDMI Audio.
About the KD-HDDA1x2Pro; KD-HDDA1x3Pro; KD-HDDA1x4Pro
Distribution of one HDMI input to multiple (2, 3, or 4) HDMI outputs
›
Supports all SD, HD, and VESA (VGA, SVGA, XGA, WXGA, SXGA, UXGA) resolutions up to
›
1080p (60Hz & 50Hz)
SD & HD: 480i, 480p, 720p, 1080i, 1080p
»
VESA: From 640x480p up to 1920x1200p
»
EDID and HDCP Transparency between source and displays
›
Can be used to strip audio from the HDMI input and send it to external digital or analog audio
›
outputs
Supports signal rates up to 10.2 Gb per second
›
Supports HDMI and DVI-D
›
Compliant with all HDMI
›
Input and Output status indicated by LED lights
›
Firmware upgradable
›
Rack mountable
›
Advanced HDMI Features
®
3D – Capability to pass 3D stereoscopic signal formats
›
Accessories
External power supply: 5V 2A
›
HDMI Lacing Clips
›
Rack Ears
›
Operating Instructions
›
Warranty Card
›
HDMI/DVI Distribution Amplifiers are designed and engineered
™
versions and HDCP copyright protection
®
Distribution Amplifiers are
™
1
