Key Digital Chroma KD-HDMI2X4P Specifications

Video/audio hdmi switcher and distribution amplifier chroma series
Hide thumbs Also See for Chroma KD-HDMI2X4P:

Advertisement

Quick Links

Video/Audio Distribution Amps
KD-HDMI 2 X  P
KD-HDMI2XP is a Video/Audio HDMI switcher and distribution amplifier capable
of switching 2 HDMI/DVID (up to 1080p) Inputs and distributing Input to  Outputs
Key Benefits
4
Switches between two HDMI/DVID video sources with
analog or digital (PCM, Optical, or HDMI) audio and
distributes to all 4 outputs
4
Supports analog, coaxial digital (PCM) and
Optical (Toslink) audio
4
Supports any HDMI/DVID resolution at 50 Hz and 60 Hz
4
Decodes HDMI digital audio into Coaxial PCM digital audio
for output on white RCA L/PCM connector
Key Solutions
Switches 2 HDMI Video/Audio sources for distribution to 4 displays
Can be cascaded to support up to 100 outputs or displays
Converts optical (Toslink) digital audio to coaxial digital audio
Control systems supported via RS-232/IR: AMX (supports AMX DDDP – Dynamic Device
Discovery Protocol), Crestron, Control4, RTI, Universal, Xantech and more

NEW
4
iAS
(Intelligent Auto Sense) auto senses signal presence
and switches to active input
4
LEDs indicate the selected source and
input/output status
4
Flexible EDID (Handshake) Control for any output
4
Incorporates 7 Key Digital
Exclusive Technologies
®
4
Optical IR, Serial IR, RS-232, Front Panel Controls
General Info
Regulation: CE, RoHS
Power: 100VAC to 240VAC,
50Hz and 60Hz
Rack Mount: Mounting Flanges
Remote Control: Included
Enclosure: Black Metal
Dimensions:
10" x 4 . 5 " x 1 . 5 "
Shipping Carton Dimensions:
17" x 5 . 5 " x 5"
Product Weight: 3 . 5 lbs
Shipping Weight: 6 lbs
Retail Application
Model: KD-HDMI2XP
Plasma/LCD
K D
- H D
M I
X H
D M
I
K D
- H D
M I
X H
D M
I
Optical IR
c k
B a
Optical IR
Key Digital
Exclusive Technologies
®
Plasma/LCD
Plasma/LCD
Plasma/LCD
KD-HDMI2x4P
n t
F r o
Serial IR
RS232 Control
Cable Box
HD DVD or
Blu-Ray
