Toshiba IK-CU51 Instruction Manual page 7

Camera control unit
Table of Contents

Advertisement

1
CAMERA terminal
2
POWER switch
3
POWER indicator
4
AGC switch
5
WB switch
6
White balance adjust control
7
FUNC button
8
UP button
9
DOWN button
p
DC IN 12V terminal
q
EXT SYNC terminal
w
S-VIDEO terminal
e
VIDEO terminal
r
REMOTE terminal
t
FUNC LOCK switch
Connects to the camera head.
Turns on and off the camera control unit.
Lights up when the power is turned on.
Selects the gain mode. (AGC OFF/AGC ON/SENS UP)
Selects the white balance mode. (MANU/SET/AUTO)
Adjusts the R gain and B gain with the white balance
mode set to MANU by the WB switch
Determines the setting indication contents when the set-
ting menu is displayed on the screen.
Selects the setting item when the setting menu is dis-
played on the screen. (When the WB switch
SET, pressing the UP button for more than 2 sec. acti-
vates the white balance SET operation.)
Selects the setting item when the setting menu is dis-
played on the screen.
Accepts a DC power supply (12V).
Accepts an external sync signal to synchronize the cam-
era output signal with external signal.
Connects terminal to S input terminal of a monitor or a
VCR, etc.
Can be used at the same time as video terminal.
Connects terminal to video input terminal of a monitor
or a VCR, etc.
Can be used at the same time with the S-VIDEO termi-
nal.
Controls the functions via RS232C.
Locks the switches and control on the front panel. When
the FUNC LOCK switch is set to ON, all settings except
for the POWER switch
setting menu are locked out.
5
.
2
and the file item of the screen
5
is set to
7
